Sparkle Technology Intel Arc B580 Luna OC 12 GB GDDR6

12GB GDDR6, TORN Cooling 2.0, Axial Fan, Breathing Light, Metal Backplate

Key Features

• TORN Cooling 2.0
• Metal Backplate, Pre-Installed
• Ray Tracing
• Variable Rate Shading (VSR)
• DirectX 12 Ultimate
• Vulkan 1.3
• OpenGL 4.6
• OpenCL 3.0
• Adaptive Sync
• AV1 Encode / Decode
• VP9 Bitstream & Decoding
• Intel Deep Link Hyper Compute
• Intel Deep Link Hyper Encode
• Intel Deep Link Stream Assist

Description

The SPARKLE Intel® Arc™ B580 TITAN Luna OC Graphics Card, offers high-resolution gaming with Intel
XeSS AI upscaling, ray tracing, and 8K media support, plus accelerated AI features for enhanced
creation and editing through Intel AI Playground.
New TITAN series equipped TORN 2.0 Cooling with triple customized AXL fans, 2.2-slot design and fullmetal backplate. A blue breathing light effect has added a touch of elegance to your gaming setup.

Specifications

Processor
Graphics processor family	Intel
Processor frequency	2740 MHz
Parallel processing technology support	Not supported
Maximum displays per videocard	4
CUDA	No
Maximum resolution	7680 x 4320 pixels
Graphics processor	Arc B580
Ray accelerators	20
Memory
Discrete graphics card memory	12 GB
Memory bandwidth (max)	456 GB/s
Memory bus	192 bit
Graphics card memory type	GDDR6
Ports & interfaces
HDMI version	2.1
HDMI ports quantity	1
DisplayPort version	2.1
DisplayPorts quantity	3
Interface type	PCI Express x8 4.0
Video
OpenCL version	3.0
DirectX version	12 Ultimate
OpenGL version	4.6
HDMI	Yes
HDMI version	2.1
Dual Link DVI	No
Performance
OpenCL version	3.0
DirectX version	12 Ultimate
OpenGL version	4.6
Dual Link DVI	No
TV tuner integrated	No
Intel® Xe Matrix Extensions (Intel® XMX) Engines	160
Xe-cores	20
NPU performance up to	233 TOPs
Design
Number of fans	3 fan(s)
Cooling type	Active
Number of slots	2.2
Software
Windows operating systems supported	Windows 10, Windows 11
Power
Supplementary power connectors	1x 8-pin
Power consumption (typical)	200 W
Minimum system power supply	600 W
Power supply location	Top
Weight & dimensions
Number of slots	2.2
Weight	954 g
Height	117 mm
Depth	44 mm
Length	315 mm
Technical details
Cooling type	Active
TV tuner integrated	No
System requirements
Windows operating systems supported	Windows 10, Windows 11
Minimum system requirements	PCI-Express compliant MB with one x16 PCIe slot
Minimum system power supply	600 W
Minimum RAM	8000 MB
Minimum processor	10th Gen Intel Core / AMD Ryzen 3000 Series Processors or newer with compatible motherboards supporting Resizable BAR / Smart Access Memory
Packaging data
Package type	Box
Other features
HDMI	Yes
