Tripp Lite DWF4585X Fixed Wall Mount for 45" to 85" TVs and Monitors

Fixed Wall Mount for 45" to 85" TVs and Monitors

Key Features

• Fits most flat-panel displays from 45 to 85 in.
• Hangs out of sight for a sleek, professional appearance
• Adjustable mounting rails compensate for off-center wall studs
• Supports up to 200 lbs (90.7 kgs)

Description

The VESA-compliant DWF4585X Fixed Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 45 to 85 inches. The low-profile mount is concealed behind the display to give a sleek, professional appearance. Frame is open for easy wall access. Mounting rails adjust horizontally to compensate for off-center wall studs. Built-in bubble level allows accurate display leveling. Durable all-metal frame with scratch-resistant powder-coated finish supports up to (90.7 kgs). Mounting hardware included. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 500 x 300 mm, 500 x 400 mm, 600 x 300 mm, 600 x 400 mm, 800 x 300 mm and 800 x 400 mm.

Specifications

Mounting
Mounting type	Wall
Minimum screen size	114.3 cm (45")
Panel mounting interface	200 x 200,300 x 300,400 x 200,400 x 400,600 x 400,800 x 400
Number of displays supported	1
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	800 x 400 mm
Maximum screen size	2.16 m (85")
Maximum weight capacity	90.72 kg
Ergonomics
Height adjustment	No
Technical details
Number of displays supported	1
Product colour	Black
Mounting type	Wall
Country of origin	China
Design
Product colour	Black
Housing material	Metal
Weight & dimensions
Width	848.4 mm
Depth	36.1 mm
Height	439.9 mm
Weight	2.59 kg
Packaging data
Package width	160 mm
Package depth	894.1 mm
Package height	50.8 mm
Package weight	3.31 kg
Logistics data
Master (outer) case width	297.2 mm
Master (outer) case length	901.7 mm
Master (outer) case height	172.7 mm
Master (outer) case gross weight	21 kg
Products per master (outer) case	6 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332186475
Harmonized System (HS) code	85299097
Other features
Mounting type	Wall
Country of origin	China
