Neomounts WL40-550BL18 TV mount wall 43-75" - full motion - easy install

SKU WL40-550BL18
£164.29
£118.31
£164.29
£118.31
Excluding taxes
Neomounts LEVEL-550 WL40-550BL18 Full motion TV mount wall - 43-75" - max 45 kg - VESA 200x100-800x400 - d 5,5-71 cm - Easy Install-model - black

Description

The Neomounts WL40-550BL18 LEVEL is a full motion wall mount for flat screens up to 75" with a maximum weight capacity of 45 kg. The versatile tilt (18°) and swivel (54°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.

The LEVEL-550 wall mount has a depth of 5,5-71 cm and is suitable for screens that meet VESA hole pattern 200x100 to 800x400 mm.

The WL40-550BL18 features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.

Specifications

Mounting
Maximum weight capacity (per display) 45 kg
Mounting type Wall
Minimum screen size 109.2 cm (43")
Panel mounting interface 200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400,680 x 300,800 x 200,800 x 400
Number of displays supported 1
Minimum VESA mount 200 x 100 mm
Maximum VESA mount 800 x 400 mm
Maximum screen size 190.5 cm (75")
Maximum weight capacity 45 kg
Ergonomics
Height adjustment No
Cable management Yes
Tilt angle range -3 - 15°
Swivel angle range 0 - 54°
Swivel angle 54°
Angle of rotation 6°
Pivot angle -3 - 3°
Distance to the wall (min) 5.5 cm
Distance to the wall (max) 71 cm
Rotating Yes
Tilt adjustment Yes
Swivelling Yes
Type Full motion
Technical details
Cable management Yes
Angle of rotation 6°
Pivot angle -3 - 3°
Number of displays supported 1
Distance to the wall (min) 5.5 cm
Distance to the wall (max) 71 cm
Product colour Black
Mounting type Wall
Country of origin China
Package net weight 11.7 kg
Master (outer) case net weight 22.1 kg
Quantity per pack 1 pc(s)
Lockable Not lockable
Design
Cable management Yes
Product colour Black
Housing material Steel
Packaging content
Mounting kit Yes
Weight & dimensions
Width 850 mm
Depth 55 mm
Height 436 mm
Weight 9.9 kg
Depth (max) 5.5 cm
Packaging data
Package width 882 mm
Package depth 340 mm
Package height 65 mm
Package weight 11.7 kg
Mounting kit Yes
Logistics data
Master (outer) case width 902 mm
Master (outer) case length 145 mm
Master (outer) case height 360 mm
Master (outer) case gross weight 24 kg
Products per master (outer) case 2 pc(s)
Master (outer) case net weight 22.1 kg
Products per pallet (EU) 40 pc(s)
Harmonized System (HS) code 7326909890
Other features
Mounting type Wall
Country of origin China
