MSI MAG FORGE 320R AIRFLOW Micro Tower Transparent, White

Midi Tower, ATX / Micro-ATX / Mini-ITX, 472.5 x 210 x 498 mm, 7.05 kg

Key Features

• Supports up to 360 mm AIO liquid cooler and large 40 series GPU
• Supports up to 11 x system fans configuration, providing ventilation and stable performance to the whole system
• Built-in ARGB fans and control board, providing striking lighting and vivid lighting effects
• Tempered Glass Side Panel displays RGB lighting effects
• The Magnetic Dust Filter on the top vents being easily remove for cleaning
• DIY Friendly cables make your DIY process easier and create more possibilities to your system
• LED Switch button provides intuitively control & 9 lighting effects

Description

UNITE AS ONE
The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.

MESH CERTIFIED MAKES IT WORK
The front mesh panel allows air to flow into the case easily without obstruction, providing the best system cooling performance. The micro-atx chassis provide small footprint but big perfromance.

HEAT DISSIPATION
You don't need to worry about system cooling with the help of the gaming cases.

HARDWARE COMPATIBILITY
The gaming cases offers extensive support for the installation of your hardware components.

EASY TO INSTALL
The gaming case has many features that make the installation process all the easier.

FANCY APPEARANCE
Build and display the coolest PC with controllable ARGB lighting.

Specifications

Technical details
Number of 5.25" bays	0
Number of 3.5" bays	1
Number of 2.5" bays	2
Supported motherboard form factors	micro ATX, Mini-ITX
Supported HDD sizes	2.5,3.5"
Suitable for	Gaming
Side window	Yes
Reset button	Yes
Product colour	Transparent, White
Maximum CPU cooler height	16 cm
Maximum graphics card length	39 cm
Maximum PSU length	20 cm
Type	PC
Form factor	Micro Tower
Material
Material	Mesh, Plastic
Indication
LED indicators	Yes
Illumination location	Case fans
Illumination colour	Multi
Illumination	Yes
Ergonomics
Reset button	Yes
LED indicators	Yes
On/off button	Yes
Design
Anti-dust filter	Yes
Material	Mesh, Plastic
Number of 5.25" bays	0
Number of 3.5" bays	1
Number of 2.5" bays	2
Supported motherboard form factors	micro ATX, Mini-ITX
Suitable for	Gaming
Side window	Yes
Reset button	Yes
LED indicators	Yes
Illumination location	Case fans
Illumination colour	Multi
Illumination	Yes
Product colour	Transparent, White
Maximum CPU cooler height	16 cm
Maximum graphics card length	39 cm
Maximum PSU length	20 cm
Type	PC
Form factor	Micro Tower
On/off button	Yes
Tempered glass panel(s)	Yes
Power supply
Power supply included	No
Power supply location	Bottom
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Audio input	Yes
Audio output	Yes
USB 2.0 ports quantity	0
Cooling
Front fans installed	3x 120 mm
Number of front fans supported (max)	3
Front fans diameters supported	120,140 mm
Number of side fans supported (max)	2
Side fans diameters supported	120 mm
Rear fans installed	1x 120 mm
Number of rear fans supported (max)	1
Rear fans diameters supported	120 mm
Number of top fans supported (max)	3
Top fans diameters supported	120,140 mm
Storage
HDD/SSD combo cage	Yes
Supported HDD sizes	2.5,3.5"
Weight & dimensions
Width	472.5 mm
Depth	210 mm
Height	498 mm
Weight	7.05 kg
Packaging data
Package weight	8.35 kg
