DrayTek Vigor 2865 | VDSL/ADSL Router | Firewall

Vigor 2865 wired VDSL router VDSL2 (Superfast Fibre) and Gigabit Ethernet WAN Router Multi-WAN Gigabit Performance Router with Load-Balancing & Failover Up to 950Mbps Firewall Throughput for Ethernet WAN 5+1 Gigabit RJ-45 LAN Ports Up to 800Mbps VPN Throughput with IPsec acceleration

Key Features

• Download speed up to 300 Mbps
• Recommended for 30 clients
• Delivers link rate up to 3 Gbps
• IPsec VPN throughput up to 300 Mbps

Description

Vigor2865 Series is a VDSL2 35b/ADSL2+ Security Firewall router integrating a DSL modem which is compatible with variants of ADSL and VDSL, including profile 35b supervectoring. There is also a Gigabit Ethernet WAN port for broadband connections to share the traffic load or serve as a failover connection. 3G/4G/LTE USB modem can also be attached to the USB ports of the router. The 2865 LTE series includes models with built-in 802.11ac Wave 2 wireless standard and VoIP gateway.

VoIP First
VoIP is always with top priority! With default UDP 5060 port (configurable), VoIP QoS is out-of-box ready.

Improve Experience for Business-Critical Apps
Select your business critical apps, and easily put them into QoS classes.

Flexible Bandwidth Allocation
Bandwidth will be reserved for high-priority classes, and can be used by low-priority classes when available.

Specifications

Ethernet LAN features
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Network
Network address translation (NAT)	Yes
Networking standards	IEEE 802.1Q
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
WAN connection
SFP WAN	No
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes
DSL features
ADSL	Yes
ADSL2	Yes
ADSL2+	Yes
VDSL	Yes
VDSL2	Yes
Management features
Web-based management	Yes
Quality of Service (QoS) support	Yes
Ports & interfaces
USB ports quantity	2
USB version	2.0
Ethernet LAN (RJ-45) ports	5
Protocols
DHCP server	Yes
DHCP client	Yes
Technical details
On/off switch	Yes
Product colour	Grey, White
Harmonized System (HS) code	85176990
Security
Network address translation (NAT)	Yes
Firewall	Yes
Security algorithms	WEP, WPA, WPA2
Access Control List (ACL)	Yes
Design
On/off switch	Yes
Product colour	Grey, White
Power
Power source type	AC
Output voltage	12 V
AC input voltage	220 - 240 V
Power consumption (typical)	24 W
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	241 mm
Depth	166 mm
Height	46 mm
Weight	620 g
Packaging data
AC adapter included	Yes
Quick start guide	Yes
Logistics data
Harmonized System (HS) code	85176990
Packaging content
AC adapter included	Yes
Quick start guide	Yes
