DrayTek 2767 VDSL 2.5G wired router 2.5 Gigabit Ethernet White

Vigor 2767 VDSL 2.5Gb Ethernet Router

Key Features

• VDSL2 or 2.5Gb Ethernet Router with Failover
• 1x 2.5 Gigabit RJ-45 switchable WAN/LAN Port
• 3x Gigabit RJ-45 LAN Ports
• In total 4 (3+1) LAN ports (1 is the WAN/LAN switchable)
• Up to 2.3Gbps Firewall Throughput
• Up to 300Mbps IPsec VPN Throughput
• 16x LAN-to-LAN & Remote Teleworker VPN Tunnels
• SPI Firewall and Content Filtering
• Compatible with VigorACS central management platform

Description

The DrayTek Vigor 2767 is a powerful, future-ready router engineered to deliver secure, reliable, and ultra-fast internet connectivity for small offices, home offices, and SME businesses. Running on DrayOS 5, it combines modern performance with flexible configuration, making it ideal for today’s Superfast Fibre services and tomorrow’s multi-gigabit broadband. A dedicated WAN interface supports VDSL2 and ADSL2+ connection, while a 2.5 Gigabit Ethernet switchable WAN/LAN port provides versatility for FTTP services or as a backup failover. With firewall throughput up to 2.3Gbps, the Vigor 2767 handles demanding workloads such as large file transfers, 4K video streaming, cloud services, and online gaming with ease. Its design ensures smooth, responsive performance across multiple devices, delivering reliable connectivity for both work and entertainment.

Specifications

Ethernet LAN features
Ethernet LAN data rates	100,1000,2500 Mbit/s
Full duplex	Yes
Network
Guest access	Yes
Wake-on-LAN ready	Yes
Network address translation (NAT)	Yes
Internal modem	Yes
Port forwarding	Yes
Flow control support	Yes
Traffic control	Yes
Ethernet LAN data rates	100,1000,2500 Mbit/s
Full duplex	Yes
Throughput	2.3 Gbit/s
Static route	Yes
Multicast support	Yes
Policy-based routing	Yes
VLAN support	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Performance
Traffic control	Yes
Firmware upgradeable	Yes
WAN connection
SFP WAN	No
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes
DSL features
Internal modem	Yes
ADSL2+	Yes
DSL	Yes
VDSL2	Yes
Management features
Wake-on-LAN ready	Yes
Universal Plug and Play (UPnP)	Yes
Firmware upgradeable	Yes
Web-based management	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
WPS push button	No
Ports & interfaces
Gigabit Ethernet (copper) ports quantity	4
USB ports quantity	2
USB version	2.0
RJ-11 ports quantity	1
DC-in jack	Yes
WAN/Ethernet LAN ports quantity	1
Protocols
Routing protocols	BGP, OSPF, RIP-1, RIP-2, RIPng
DMZ support	Yes
DHCP server	Yes
DHCP client	Yes
Technical details
On/off switch	Yes
Rack mounting	No
Firmware upgradeable	Yes
LED indicators	DSL, LAN, Power, USB
Product colour	White
WPS push button	No
Policy-based routing	Yes
Security
Guest access	Yes
DoS attack prevention	Yes
IP address filtering	Yes
Network address translation (NAT)	Yes
URL filtering	Yes
Firewall	Yes
Security algorithms	3DES, AES, DES, HTTPS, IPSec, OWE, SSH, WEP, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
VPN tunnels quantity	16
System event log	Yes
MAC address filtering	Yes
VPN support	IPsec IKEv1, IKEv2, IKEv2 EAP IPsec-XAuth OpenVPN WireGuard EasyVPN - New!
ARP attack prevention	Yes
Access Control List (ACL)	Yes
ICMP attack prevention	Yes
Packaging content
AC adapter included	Yes
Quick start guide	Yes
Cables included	LAN (RJ-45)
Design
Housing material	Plastic
Wall mountable	Yes
On/off switch	Yes
Rack mounting	No
LED indicators	DSL, LAN, Power, USB
Product colour	White
Power
Power consumption (typical)	13.7 W
Power consumption (max)	13.7 W
Weight & dimensions
Width	207 mm
Depth	131 mm
Height	42 mm
Weight	455.3 g
Packaging data
AC adapter included	Yes
Quick start guide	Yes
Cables included	LAN (RJ-45)
Other features
WPS push button	No
