Sharp MultiSync E659 Digital signage flat panel 165.1 cm (65") LCD 350 cd/m² 4K Ultra HD Black

LCD 65", IPS, Direct LED, 3840 x 2160, 350 cd/m², 1200:1, 1.07 (8bit + FRC), 1453 x 829 x 59.7

Key Features

• Unhindered readability – a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
• Standardised functionality – shares a common identity with the wider Sharp display portfolio, ensuring unified operation and remote device management, and consistent styling for a seamless user experience.
• Effortless plug-and-play signage – the integrated USB MediaPlayer enables native UHD content playback with auto-start functionality, delivering instant digital signage without the need for external hardware or content management systems.
• Flexible orientation – designed for both portrait and landscape installation, with uniform bezel width on all sides to ensure a clean, professional look in any configuration.

Description

Professional performance, affordable value

The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.

Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget

Specifications

Display
LED backlight	Yes
Panel type	IPS
Display number of colours	1.073 billion colours
LED backlighting type	Direct-LED
Touchscreen	No
Active display area (W x H)	1428.48 x 803.52 mm
Display technology	LCD
Display diagonal	165.1 cm (65")
Display resolution	3840 x 2160 pixels
Display brightness	350 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.372 x 0.372 mm
Display diagonal (metric)	164 cm
Vertical scan range	24 - 75 Hz
Native aspect ratio	16:9
Horizontal scan range	31.5 - 135 kHz
Haze rate	25%
Ports & interfaces
USB connector type	USB Type-A, USB Type-C
USB port	Yes
RS-232C	Yes
Wi-Fi	No
PC Audio in	Yes
DisplayPorts quantity	0
Ethernet LAN	Yes
HDMI ports quantity	4
Ethernet LAN data rates	100 Mbit/s
DVI port	No
Ethernet LAN (RJ-45) ports	1
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	4
HDMI input ports quantity	2
HDMI output ports quantity	2
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (top)	1.08 cm
Bezel width (side)	1.08 cm
Bezel width (bottom)	1.08 cm
Product colour	Black
Panel mounting interface	400 x 400 mm
VESA mounting	Yes
Mounting type	Wall
Performance
Purpose	Universal
Wi-Fi	No
Power
Power consumption (sleep)	0.5 W
Power consumption (typical)	125 W
Power consumption (standby)	2 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	115 kWh
Weight & dimensions
Display width	1453 mm
Display depth	59.7 mm
Display height	829 mm
Display weight	16.5 kg
Packaging data
Package width	1635 mm
Package depth	160 mm
Package height	987 mm
Package weight	23 kg
Batteries included	Yes
Remote control included	Yes
Cables included	AC
Packaging content
Batteries included	Yes
Remote control included	Yes
Cables included	AC
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 80%
Technical details
VESA mounting	Yes
USB connector type	USB Type-A, USB Type-C
Panel type	IPS
LED backlighting type	Direct-LED
Network
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	100 Mbit/s
Other features
USB connector type	USB Type-A, USB Type-C
Panel type	IPS
Wi-Fi	No
Display technology	LCD
Bezel width (top)	1.08 cm
Bezel width (side)	1.08 cm
Bezel width (bottom)	1.08 cm
Energy efficiency scale	A to G
