Sharp MultiSync M432 Digital signage flat panel 108 cm (42.5") LCD 550 cd/m² 4K Ultra HD Black

42.5", IPS, 3840 x 2160, 550 cd/m², 8000:1, 0.245 x 0.245, 1.073M, 178°/178°

Key Features

• Seamless meeting workflows – a single USB-C cable transmits video, data, and power for instant, clutter-free meeting setups. As the established standard for modern collaboration spaces, USB-C supports frictionless BYOD experiences.
• Unhindered readability – a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
• Security assured – 802.1x support over LAN enables high-level security for corporate networks, giving peace of mind for IT teams and enterprise environments.
• Enhanced imaging precision – when brand consistency and corporate identity are important, NEC’s SpectraView Engine provides full control over colour, gamma, and uniformity for accurate and impactful content.
• Broad AV compatibility – fully interoperable with leading meeting room platforms including Crestron (XiO Cloud), Cisco Webex, Q-Sys, and Microsoft Teams, ensuring effortless integration and future-proof scalability.

Description

Built to perform, designed to last

The versatile solution for professional display applications, the Sharp MultiSync® M2 Series (32" up to 98") is purpose-built for demanding signage and meeting room environments. With native USB-C connectivity and broad compatibility with platforms such as Crestron, Cisco Webex, and Microsoft Teams, it enables seamless BYOD collaboration and future-ready integration, while 802.1x LAN support ensures enterprise-grade network security. Featuring class-leading 550 cd/m² brightness, a high-haze panel to minimise glare, and NEC’s trusted SpectraView Engine, the M2 Series delivers outstanding visual performance with unmatched colour precision.

As part of the new Sharp-branded display family, the MultiSync® M2 Series builds on NEC’s legacy of quality and reliability to drive greater efficiency and long-term value. Its proven modular design supports custom computing options (Raspberry Pi or Intel® SDM) and flexible connectivity (e.g. AV-over-IP), ensuring lasting versatility, performance, and sustainability.

Specifications

Display
LED backlight	Yes
Panel type	IPS
Display number of colours	1.073 billion colours
LED backlighting type	Direct-LED
Touchscreen	No
Active display area (W x H)	941.2 x 529.4 mm
Display technology	LCD
Display diagonal	108 cm (42.5")
Display resolution	3840 x 2160 pixels
Display brightness	550 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.245 x 0.245 mm
Display diagonal (metric)	108 cm
Vertical scan range	23 - 76 Hz
Native aspect ratio	16:9
Horizontal scan range	15 - 135 kHz
Haze rate	25%
Ports & interfaces
USB connector type	USB Type-A, USB Type-C
DisplayPorts out	1
USB port	Yes
DisplayPorts in	1
Wi-Fi	No
DisplayPorts quantity	2
Ethernet LAN	Yes
HDMI ports quantity	3
Ethernet LAN data rates	100 Mbit/s
DVI port	No
Audio (L/R) in	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	2
USB ports quantity	4
HDMI input ports quantity	2
HDMI output ports quantity	1
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (top)	9.9 mm
Bezel width (side)	9.9 mm
Bezel width (bottom)	1.39 cm
Product colour	Black
Panel mounting interface	300 x 300 mm
VESA mounting	Yes
Screen shape	Flat
Performance
Purpose	Universal
Wi-Fi	No
Power
Power consumption (typical)	75 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input voltage	100 - 240 V
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	66 kWh
Weight & dimensions
Display width	965 mm
Display depth	66.5 mm
Display height	557.2 mm
Display weight	13.5 kg
Packaging data
Package width	1070 mm
Package depth	161 mm
Package height	675 mm
Package weight	18 kg
Remote control included	Yes
Cables included	AC
Packaging content
Remote control included	Yes
Cables included	AC
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 80%
Technical details
VESA mounting	Yes
USB connector type	USB Type-A, USB Type-C
Panel type	IPS
DisplayPorts out	1
DisplayPorts in	1
LED backlighting type	Direct-LED
Other features
USB connector type	USB Type-A, USB Type-C
Panel type	IPS
DisplayPorts out	1
DisplayPorts in	1
Wi-Fi	No
Display technology	LCD
Bezel width (top)	9.9 mm
Bezel width (side)	9.9 mm
Bezel width (bottom)	1.39 cm
Input voltage	100 - 240 V
