Vestel PF55B-2 Signage Display 165.1 cm (65") LED 500 cd/m² 4K Ultra HD Black 16/7

55", 3840 x 2160 (16:9) UHD, Slim DLED, 500 cd/m², OPS/SDM/NUC, 180 W, 110 - 240 VAC, 50/60 Hz

Key Features

• OPS/SDM/NUC Module Support
• Embedded IR/IR Extender Options
• 30° Tilting Installation
• Application Area: Retail, QSR, Transportation, Control Room

Description

Daisy Chain
The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode.

Usb Security
This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.

Usb Auto-Play
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.

Subtle Design
This series’ displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, detachable power plug and IR extender.

SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.

Signal Failover
Our displays have a protection for “No Signal”. If the source is disconnected, the display will either show your customized banner or search for any other signal from video sources. Since blank screen is the worst case scenario for advertisement, failover is one of the critical feature in our signage displays.

Scheduler
The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists.

Pixel Shifting
The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience.

Optional OPS Support
All our products in this series have an optional OPS (Open Pluggable Standard) slot. OPS will empower your screens with enhanced processing power and ability to choose Windows or Android as your operating system to fit your specific application.

Open Platform Support
Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.

External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.

Display Control
Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.

Specifications

Display
LED backlight	Yes
LED backlighting type	Slim Direct-LED
Active display area (W x H)	1209.6 x 680.4 mm
Display technology	LED
Display diagonal	165.1 cm (65")
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	50000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Panel life	50000 h
Native aspect ratio	16:9
Native refresh rate	60 Hz
Haze rate	1%
Ports & interfaces
USB port	Yes
HDMI version	2.0
Ethernet LAN	Yes
HDMI ports quantity	2
DVI port	No
VGA (D-Sub) input ports	1
Audio (L/R) in	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
USB version	2.0
USB ports quantity	3
OPS module slot	Yes
HDMI input ports quantity	2
SDM module slot	Yes
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Placement supported	Indoor
Orientation	Horizontal
Bezel width (top)	9 mm
Bezel width (side)	9 mm
Bezel width (bottom)	1.1 cm
Product colour	Black
Panel mounting interface	400 x 400 mm
Certification	CE, EMC
VESA mounting	Yes
Screen shape	Flat
Performance
Purpose	Universal
Operating hours (hours/days)	16/7
On Screen Display (OSD)	Yes
Panel life	50000 h
Power
Power consumption (max)	180 W
Power consumption (typical)	138 W
Power consumption (standby)	0.5 W
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Weight & dimensions
Width (with stand)	1236 mm
Height (with stand)	709 mm
Depth (with stand)	83 mm
Weight (with stand)	17 kg
Display width	1236 mm
Display depth	63 mm
Display height	709 mm
Packaging data
Package width	1369 mm
Package depth	165 mm
Package height	874 mm
Package weight	22 kg
Remote control included	Yes
Mounting kit	Yes
Cables included	IR, Power
Packaging content
Remote control included	Yes
Mounting kit	Yes
Cables included	IR, Power
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Certificates
Certification	CE, EMC
Technical details
VESA mounting	Yes
LED backlighting type	Slim Direct-LED
Weight (with stand)	17 kg
Sustainability compliance	Yes
Compliance certificates	CE, Electromagnetic Compatibility (EMC)
Features
Suitable for indoor use	Yes
Video wall controller included	Yes
Other features
Width (with stand)	1236 mm
Power consumption (max)	180 W
Height (with stand)	709 mm
Display technology	LED
Depth (with stand)	83 mm
Bezel width (top)	9 mm
Bezel width (side)	9 mm
Bezel width (bottom)	1.1 cm
Weight (with stand)	17 kg
OPS module slot	Yes
