Avocor AVK-8510 Signage Display 2.16 m (85") LED Wi-Fi 450 cd/m² 4K Ultra HD Built-in processor Android 16/7

Avocor K-10 Series 85" 4K Display

Key Features

• COMPLETE RANGE OF SIZES - With sizes ranging from 55” to 98”, the K Series ensures a perfect fit for a wide variety of use cases, from small huddle style meetings to expansive auditoriums
• SUPERIOR VISUAL PERFORMANCE - With 4K resolution featuring QLED and HDR, the K Series features stunning visual clarity, ensuring content is vibrant, vivid and engaging
• STUNNING BRIGHTNESS AND COLOUR - 450 nits of high brightness and 90% DCI-P3 for brilliant color accuracy, K Series displays are even visible in well
• COMPREHENSIVE CONNECTIVITY - With multiple HDMI ports, USB-A, LAN, and WiFi/Bluetooth support, the K Series is ready for any input source and network configuration, making installation and integration straightforward
• DISPLAYNOTE MONTAGE X RISEVISION - Featuring Montage for seamless wireless sharing and Rise Vision for dynamic digital signage, transforms idle displays into hubs of interactive team collaboration

Description

The Avocor K Series merges QLED technology’s superior visual clarity with seamless connectivity features to deliver a corporate range of displays that are ideal for modern workspaces. Designed for versatility across corporate, educational, and public settings, the K Series ranges from 55 to 98 inches, ensuring a perfect match for any space.

With advanced integration capabilities like wireless screen sharing through Montage and digital signage via Rise Vision, the K Series stands as the ultimate choice for organizations aiming to elevate their visual communication and collaboration.

The Avocor K Series encapsulates the future of professional displays, offering unmatched quality, connectivity, and ease of use in one comprehensive solution.

Specifications

Display
LED backlight	Yes
Panel type	QLED
Display number of colours	1.07 billion colours
LED backlighting type	Direct-LED
Touchscreen	No
Display technology	LED
Display diagonal	2.16 m (85")
Display resolution	3840 x 2160 pixels
Display brightness	450 cd/m²
HD type	4K Ultra HD
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Native aspect ratio	16:9
High Dynamic Range (HDR) supported	Yes
Native refresh rate	60 Hz
RGB colour space	DCI-P3
Ports & interfaces
USB connector type	USB Type-A
USB port	Yes
HDMI version	2.1
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Ethernet LAN	Yes
HDMI ports quantity	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
USB ports quantity	2
HDMI input ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	15 W
Audio
Number of built-in speakers	2
RMS rated power	10 W
Built-in speaker(s)	Yes
Design
Placement supported	Indoor
Orientation	Horizontal
Bezel width (top)	3.5 mm
Bezel width (side)	3.5 mm
Bezel width (bottom)	2.04 cm
Panel mounting interface	500 x 200 mm
VESA mounting	Yes
Screen shape	Flat
Bezel type	VNB (Very Narrow Bezel)
Performance
Operating hours (hours/days)	16/7
Miracast	Yes
Wi-Fi Direct	Yes
Firmware upgradeable	Yes
Over the Air Updates (OTA)	Yes
Wi-Fi	Yes
Power
Power consumption (max)	340 W
Computer system
Processor family	ARM Cortex
Processor model	A73
Operating system installed	Android
Internal storage capacity	32 GB
Processor manufacturer	ARM
Built-in processor	Yes
On-board graphics card model	ARM Mali-G52
Processor architecture	ARM Cortex-A73
Operating system version	14
Weight & dimensions
Display width	1894 mm
Display depth	101 mm
Display height	1097 mm
Display weight	38.6 kg
Packaging data
Package width	2050 mm
Package depth	230 mm
Package height	1280 mm
Package weight	52 kg
Batteries included	Yes
Remote control included	Yes
Packaging content
Stand included	Yes
Batteries included	Yes
Remote control included	Yes
Power adapter included	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Technical details
VESA mounting	Yes
USB connector type	USB Type-A
Stand included	Yes
Panel type	QLED
LED backlighting type	Direct-LED
Thin Client
Processor family	ARM Cortex
Processor model	A73
Operating system installed	Android
Internal storage capacity	32 GB
Logistics data
Country of origin	China
Other features
USB connector type	USB Type-A
Stand included	Yes
Panel type	QLED
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Wi-Fi	Yes
Power consumption (max)	340 W
Display technology	LED
Bezel width (top)	3.5 mm
Bezel width (side)	3.5 mm
Bezel width (bottom)	2.04 cm
