BenQ ST8602S Digital signage flat panel 2.18 m (86") LED 400 cd/m² 4K Ultra HD Black Built-in processor Android 8.0 18/7

86", TFT, 3840 x 2160, 8 Bit, 400 cd/m², Android 8.0, 3GB, 16GB, VGA, HDMI, DVI, USB-A 2.0, RS232, IR, RJ45, 600 x 400 mm, 50 kg

Description

Without connecting any external processing device, the built-in
Android™ OS allows you to access files, display contents, and start presentations directly on the display.

Edit, manage, and customise content through the X-Sign Content Management Software by
using the 150+ templates available; with the X-Sign Broadcast, you can deliver instant announcement to all your BenQ’s displays.

Combined with DMS Cloud and DMS Local, BenQ’s Device Management Solution helps you easily manage
all your BenQ displays at the same time and maximise the productivity for your workplace.

With the pre-installed TeamViewer Meeting, you can start video meetings with a simple click. The ST02S series is perfect for video conferencing solutions.

Specifications

Display
Panel type	ADS
LED backlighting type	Direct-LED
Touchscreen	No
Active display area (W x H)	1895 x 1066 mm
Display technology	LED
Display diagonal	2.18 m (86")
Display resolution	3840 x 2160 pixels
Display brightness	400 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Display diagonal (metric)	217 cm
Panel life	30000 h
Native aspect ratio	16:9
RGB colour space	NTSC
Ports & interfaces
USB port	Yes
HDMI version	2.0
Wi-Fi	No
PC Audio in	Yes
DisplayPorts quantity	0
Ethernet LAN	Yes
HDMI ports quantity	3
Ethernet LAN data rates	10,100,1000 Mbit/s
DVI port	Yes
DVI-D ports quantity	1
VGA (D-Sub) input ports	1
Ethernet LAN (RJ-45) ports	1
USB version	2.0
USB ports quantity	2
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Digital signage flat panel
Placement supported	Indoor
Product colour	Black
Panel mounting interface	600 x 400 mm
VESA mounting	Yes
Screen shape	Flat
Performance
Purpose	Universal
Operating hours (hours/days)	18/7
Wi-Fi	No
Panel life	30000 h
Power
Power consumption (typical)	317 W
Power consumption (standby)	0.5 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Energy efficiency class (SDR)	G
Energy consumption (SDR) per 1000 hours	327 kWh
Computer system
Computer system	Yes
Operating system installed	Android 8.0
Internal memory	3 GB
Internal storage capacity	16 GB
Built-in processor	Yes
Weight & dimensions
Display width	1929 mm
Display depth	79.4 mm
Display height	1100 mm
Display weight	53 kg
Packaging data
Package width	248 mm
Package depth	2130 mm
Package height	1321 mm
Package volume	64000 cm³
Remote control included	Yes
Cables included	HDMI
Packaging content
Remote control included	Yes
Cables included	HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 80%
Technical details
VESA mounting	Yes
Panel type	ADS
LED backlighting type	Direct-LED
Network
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Thin Client
Operating system installed	Android 8.0
Internal memory	3 GB
Internal storage capacity	16 GB
Logistics data
Products per pallet	5 pc(s)
Country of origin	China
Harmonized System (HS) code	8528529100
Features
Harmonized System (HS) code	8528529100
Other features
Panel type	ADS
Wi-Fi	No
Display technology	LED
