Philips 3000 series 43BDL3751T/00 Signage Display Interactive flat panel 108 cm (42.5") LCD Wi-Fi 450 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android

Signage Solutions Interactive 3000 Series

Description

Better connected – versatile multi-touch display

Delivering 24/7 operation with 450 nits of brightness, this versatile PCAP display is also designed to reduce energy consumption across the range. Engage. Inspire. Connect. With Android 13, Wave ready and no need for an external media player.

Easy to clean, with anti-glare and anti-fingerprint coating.
A flush design with no bezel bringing an edge to edge experience augmented with anti-glare glass. Easy to clean, these interactive touch screens also feature anti-fingerprint coating.

Also supporting 30° tilt – ideal for kiosk installations.
Install in portrait or landscape orientations, with the option to tilt to 30° and size variants to suit a range of installation purposes. Whether on a shelf – ideal for the 24", angled or upright for Point of Sale, configurators, order points and kiosks – with the 32" and 43", or for wayfinding – think 55".

Better visibility even in bright daylight
With 450 cd/m2 brightness for better visibility under bright lights, the Philips Interactive 3000 Series is designed to be used 24/7, making it a great selection for travel and transportation hubs, retail centres, food and beverage locations, and more. FailOver is also included enabling your display to switch automatically between primary and secondary inputs should an outage occur.

No need for external media player. 4 GB RAM + 32 GB ROM.
The ultimate in intuitive user experience, with a professional Android 13 SoC built in for easy apps and solutions integrations, and no need for an external media player. Connections include Wi-Fi and Bluetooth, as well as a USB-C port.

Remote monitoring, maintenance and management.
Manage your display and control content remotely with PPDS Wave Controller – your evolutionary ecosystem designed to support time, energy and cost efficiencies. Discover software applications to support your interactive vision from our network of proven partners on the PPDS ProStore.

Supporting business sustainability and energy savings.
Reduced power consumption compared to previous models, supporting business sustainability and energy savings.

Better connecting customers with content.
Allows seamless connectivity, enabling easily access and engagement with content.

Activated out of the box for hassle-free peace of mind.
Reliable, worry-free protection for your displays, with a three-year warranty automatically in place from the start, eliminating any setup effort.

Specifications

Display
Panel type	ADS
Display number of colours	1.07 billion colours
Number of simultaneous touchpoints	10
Touchscreen	Yes
Display technology	LCD
Display diagonal	108 cm (42.5")
Display resolution	3840 x 2160 pixels
Display brightness	450 cd/m²
HD type	4K Ultra HD
Response time	8 ms
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.245 x 0.245 mm
Display diagonal (metric)	108 cm
Native aspect ratio	16:9
Anti-glare screen	Yes
Touchscreen technology	Projected capacitive system
Native refresh rate	60 Hz
Glass thickness	3 mm
Ports & interfaces
USB connector type	Micro-USB, USB Type-A, USB Type-B, USB Type-C
DisplayPort version	1.3
USB port	Yes
DisplayPorts in	1
HDMI version	2.0
Infrared data port	Yes
Wi-Fi	Yes
DisplayPorts quantity	1
Ethernet LAN	Yes
HDMI ports quantity	2
Ethernet LAN data rates	1000 Mbit/s
DVI port	No
Audio (L/R) in	1
Audio (L/R) out	1
Ethernet LAN (RJ-45) ports	1
RS-232 interface	Yes
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
HDMI input ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	15 W
Audio
Number of built-in speakers	2
RMS rated power	20 W
Built-in speaker(s)	Yes
Design
Product design	Interactive flat panel
Orientation	Horizontal/Vertical
Bezel width (top)	2.34 cm
Bezel width (side)	2.34 cm
Bezel width (bottom)	2.34 cm
Product colour	Black
Panel mounting interface	200 x 200 mm
VESA mounting	Yes
Anti-glare screen	Yes
Mounting type	Wall
Fingerprint resistant	Yes
Wall mountable	Yes
Performance
Purpose	Commercial
On Screen Display (OSD) languages	Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
On Screen Display (OSD)	Yes
Number of OSD languages	18
HID support	Yes
Wi-Fi	Yes
Power
Power consumption (max)	145 W
Power consumption (typical)	65 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50.60 Hz
Energy efficiency scale	A to G
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	68 kWh
Computer system
Computer system	Yes
Computer system type	System on Chip (SoC)
Processor cores	3
Processor family	ARM Cortex
Processor model	A55
Operating system installed	Android
Internal memory	4 GB
Internal storage capacity	32 GB
Video formats supported	H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP8, VP9
Audio formats supported	AAC, HE-AAC, MPEG-1, MPEG-2
Image formats supported	BMP, JPEG, PNG, WEBP
Processor manufacturer	ARM
Built-in processor	Yes
On-board graphics card model	ARM Mali-G52
Processor architecture	ARM Cortex-A55
Operating system version	13
Weight & dimensions
Width (with stand)	990 mm
Height (with stand)	578.2 mm
Depth (with stand)	69.3 mm
Weight (with stand)	17.1 kg
Packaging data
Package weight	20.6 kg
Batteries included	Yes
Remote control included	Yes
Cables included	AC, RS-232, USB Type-A to USB Type-B
Packaging content
Batteries included	Yes
Remote control included	Yes
Cables included	AC, RS-232, USB Type-A to USB Type-B
Wi-Fi module included	Yes
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Technical details
VESA mounting	Yes
USB connector type	Micro-USB, USB Type-A, USB Type-B, USB Type-C
Panel type	ADS
DisplayPort version	1.3
DisplayPorts in	1
Number of simultaneous touchpoints	10
Weight (with stand)	17.1 kg
HID support	Yes
Sustainability certificates	ENERGY STAR
Warranty period	3 year(s)
Compliance certificates	BSMI, CB, CE, ETL, Federal Communications Commission (FCC), PSB, RoHS
Thin Client
Processor family	ARM Cortex
Processor model	A55
Operating system installed	Android
Internal memory	4 GB
Internal storage capacity	32 GB
Video formats supported	H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP8, VP9
Audio formats supported	AAC, HE-AAC, MPEG-1, MPEG-2
Image formats supported	BMP, JPEG, PNG, WEBP
Features
Wall mountable	Yes
Other features
USB connector type	Micro-USB, USB Type-A, USB Type-B, USB Type-C
Panel type	ADS
DisplayPort version	1.3
DisplayPorts in	1
Number of simultaneous touchpoints	10
Wi-Fi	Yes
Width (with stand)	990 mm
Power consumption (max)	145 W
Height (with stand)	578.2 mm
Display technology	LCD
Depth (with stand)	69.3 mm
Bezel width (top)	2.34 cm
Bezel width (side)	2.34 cm
Bezel width (bottom)	2.34 cm
Weight (with stand)	17.1 kg
HID support	Yes
Energy efficiency scale	A to G
