Cooler Master V4 Alpha 3DHP Black Processor Air cooler 12 cm 1 pc(s)

Intel/AMD, 2 x 3DHP / Aluminum Fins, 2x 120 mm, 0-2050 RPM / 0-1850 RPM, 107.2 m³/h / 85.8 m³/h, 2.69 mmH₂O / 1.77 mmH2O, PWM, 12 VDC, 133 x 114 x 161 mm, Black

Key Features

• Cooler Master Proprietary 3DHP technology​
• Excellent thermal dissipation​
• Pre-installed ring blade fans​
• Larger contact surface area

Description

V4 Alpha 3DHP Black

Advanced Cooling, Elevated​​

The Cooler Master V4 Alpha 3DHP Black CPU air cooler delivers exceptional cooling performance and sleek aesthetics, featuring the company’s proprietary 3DHP Technology for rapid heat dissipation and peak system efficiency to rival the performance of conventional four-heat-pipe coolers. Using just two heat pipes, it is engineered to maintain optimal processor temperatures under heavy workloads. The V4 Alpha 3DHP Black has been crafted in the shape of a classic V automotive engine but delivers performance comparable to that of one of the most efficient electric cars available. The V4 Alpha 3DHP Black CPU air cooler stands out with its innovative design and excellent performance. Built for enthusiasts and perfected for professionals, V4 Alpha 3DHP Black isn’t just a cooler, it’s the heartbeat of your high-performance machine.

Less heat pipes. More cooling efficiency.
Less noise. More reliability.

The Advanced 3DHP Internal Structure​

3DHP heat pipes use a hybrid internal structure that combines sintered powder and grooved channels in varying textures and sizes. Each section is optimized for a specific phase—evaporation, condensation, or liquid return—resulting in more efficient heat transfer than traditional designs.​

*Image for reference only; actual internal configuration may vary in the final product design.

Cooler Master Proprietary 3DHP Technology​

3DHP technology redefines heat pipe design by adding a third dimension—an extra pipe that fills the dead zone in standard U-shaped layouts. This added connection improves heat transfer in a slimmer, more efficient design.​

It delivers the cooling power of a four-pipe solution with a more streamlined layout—giving you lower temps, quieter fans, and more flexibility, whether you’re building for silence or pushing your system to the limit.​

Quieter. Stronger. Smarter.​

Fewer pipes, better performance. 3DHP’s efficient heat transfer reduces radiator turbulence and lowers fan noise across the system. Whether you’re building for silence or tuning for peak output, 3DHP delivers.​

​Pre-Installed Ring Blade Fans​

The included Mobius 120 fans features a ring blade design that cuts high-frequency noise and keeps operation smooth and quiet—especially when paired with the 3DHP module.​

Minimalist Design

The V4 Alpha 3DHP Black draws inspiration from a classic V-style automotive engine—bold, compact, and built for performance. Its unique form factor supports efficient airflow and reliable cooling, all in a design that stands out

Excellent Thermal Dissipation​

Keeps temperatures lower under the same CPU workload, helping maintain system stability and long-term reliability.​

Larger Contact Surface for Maximum Heat Transfer​

Unlike most four-pipe coolers with direct contact, our solid copper base covers more surface area. Combined with wider 3DHP heat pipes, it ensures efficient heat transfer from the CPU to the cooling array.​

CRYOFUZE THERMAL PASTE

Included high-performance thermal paste relies on nanoparticles for maximal heat transfer.

AMD & INTEL COMPATIBILITY

Features compatibility with AMD and Intel CPU sockets.

Specifications

Performance
Suitable location	Processor
Fan connector	4-pin
Pulse-width modulation (PWM) support	Yes
Fins material	Aluminium
Bearing type	Loop Dynamic Bearing (LDB)
Type	Air cooler
Fan diameter	12 cm
Supported processor sockets	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5
Maximum airflow	63.1 cfm
Maximum air pressure	2.69 mmH2O
Airflow	107.2 m³/h
Number of fans	2 fan(s)
Quantity per pack	1 pc(s)
Fan 2 rotational speed (min)	0 RPM
Fan 2 rotational speed (max)	1850 RPM
Fan 2 maximum airflow	50.5 cfm
Fan 2 maximum air pressure	1.77 mmH2O
Fan noise level (min)	20 dB
Fan noise level (max)	22.6 dB
Fan speed (min)	0 RPM
Fan speed (max)	2050 RPM
Fan's mean time to failure (MTTF)	200000 h
Design
Fan connector	4-pin
Fins material	Aluminium
Number of fans	2 fan(s)
Product colour	Black
Radiator material	Aluminum
Base plate material	Copper
Technical details
Type	Air cooler
Fan diameter	12 cm
Supported processor sockets	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5
Maximum airflow	63.1 cfm
Maximum air pressure	2.69 mmH2O
Airflow	107.2 m³/h
Number of fans	2 fan(s)
Fan connector	4-pin
Warranty period	5 year(s)
Ports & interfaces
Fan connector	4-pin
Power
Safety current	0.35 Ah
Rated voltage	12 V
Rated current	0.12 A
Fan power consumption	1.44 W
Colour
Product colour	Black
Weight & dimensions
Fan dimensions (W x D x H)	120 x 120 x 25 mm
Package depth	155 mm
Package width	155 mm
Package height	215 mm
Width	114 mm
Depth	133 mm
Height	161 mm
Packaging data
Package depth	155 mm
Package width	155 mm
Package height	215 mm
Package type	Box
Packaging content
Package type	Box
Other features
Safety current	0.35 Ah
