Synology DiskStation DS3622xs+ NAS Tower Intel® Xeon® D D-1531 16 GB DDR4 0 TB DiskStation Manager Black

Intel Xeon D-1531, 16 GB DDR4, 12x SATA HDD, RJ-45, USB 3.2, RJ-45, PCIe, 270x300x340 mm

Key Features

• Six-core Intel Xeon
• 4,719 MB/s seq. read 260,691 4K random read IOPS
• 16 GB DDR4 ECC, expandable to 48 GB
• Triple in size to 36 drives with two DX1222 expansion units

Description

High-performance mass storage
The 12-bay Synology DS3622xs+ is a powerhouse NAS perfect for the needs of small and medium business environments with intensive and multi-user workloads. Its high capacity, scalability, and processing power make it ideal for VM and container storage, fast file sharing, and as a network video recorder for large surveillance deployments. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video.

Faster performance
Enjoy a smooth experience even with multiple users running demanding applications. See the numbers that make the DS3622xs+ more efficient.

Rise to the challenge
Prepare your DS3622xs+ for the heaviest workloads or upgrade when needed as your business continues to grow. Use add-in cards to add bandwidth, fast SSD cache, or both.

Out-of-the-box data protection
Protect your data with professional backup software for your Synology NAS, other devices, and applications.

Efficient collaboration and communication
Empower your workforce to collaborate, share files, and communicate from anywhere.

Certified virtual machine storage
Synology DiskStation Manager (DSM) streamlines provisioning for and management of virtual machines with full certification for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack virtualization environments.

Synology Storage Console for VMware® or Windows platforms lets you manage storage directly from your hypervisor. VMware® VAAI integration and Windows ODX help offload storage operations and speed up data transfer, and a Kubernetes CSI driver lets you provision and manage volumes directly from the K8s CLI.

Centralized surveillance for your business
Transform the DS3622xs+ into a powerful network video recorder with Synology Surveillance Station.

Works best with Synology drives
Enjoy top quality performance for any intensive workload with drives specifically designed for Synology NAS.

Get more with DiskStation Manager
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based Synology DSM operating system.

Specifications

Storage
Total installed storage capacity	0 TB
Storage drives installed	No
Installed storage drive type	No
Number of storage drives installed	0
Supported storage drive types	HDD & SSD
Number of storage drives supported	12
Maximum supported storage capacity	200 TB
Storage drive capacity	0 GB
Hot-swap drive bays	Yes
RAID support	Yes
Supported file systems	BTRFS, Fat, HFS+, NTFS, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5"
Processor
Processor manufacturer	Intel
Processor boost frequency	2.7 GHz
CPU configuration (max)	1
Conflict-Free processor	Yes
Processor frequency	2.2 GHz
Processor family	Intel® Xeon® D
Processor model	D-1531
Processor cores	6
Number of processors supported	1
Memory
Internal memory type	DDR4
Internal memory	16 GB
Maximum RAM supported	48 GB
Memory slots	4
Memory form factor	SO-DIMM
Network
Link aggregation	Yes
Ethernet LAN	Yes
Ethernet LAN data rates	1000,10000 Mbit/s
Wake-on-LAN ready	Yes
Supported network protocols	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express x8 (Gen 3.x) slots	1
Ethernet LAN (RJ-45) ports	4
Hard drive
RAID support	Yes
Supported file systems	BTRFS, Fat, HFS+, NTFS, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Design
Fan diameter 2	12 cm
Cooling type	Active
Fan diameter	12 cm
Product colour	Black
Number of fans	2 fan(s)
Chassis type	Tower
Technical details
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Product colour	Black
Noise level	25 dB
Multilingual support	Yes
Chassis type	Tower
Number of fans	2 fan(s)
Harmonized System (HS) code	84714100
Performance
Browser supported	Safari, Google Chrome, Firefox, Microsoft Edge
Type	NAS
Device class	Home & Home Office
Backup function	Yes
Server operating systems supported	Windows Server 2016, Windows Server 2019
Web-based management	Yes
Operating system installed	DiskStation Manager
Noise level	25 dB
Multilingual support	Yes
Access Control List (ACL)	Yes
Cooling
Cooling type	Active
Fan diameter	12 cm
Number of fans	2 fan(s)
Security
Access Control List (ACL)	Yes
Software
Server operating systems supported	Windows Server 2016, Windows Server 2019
Operating system installed	DiskStation Manager
Management features
Web-based management	Yes
Power
Power consumption (HDD standby)	54.33 W
Power supply location	Built-in
Power supply unit (PSU) capacity	550 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	94.42 W
Number of power supply units	1
Weight & dimensions
Width	300 mm
Depth	340 mm
Height	270 mm
Weight	9.8 kg
Packaging content
Cables included	AC, LAN (RJ-45)
Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	1.00
Intel TSX-NI	Yes
Intel Trusted Execution Technology	Yes
Intel Secure Key Technology version	1.00
Intel Enhanced Halt State	Yes
Intel 64	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
Embedded options available	No
System requirements
Server operating systems supported	Windows Server 2016, Windows Server 2019
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC CE BSMI VCCI RCM UKCA EAC KC UL
Logistics data
Harmonized System (HS) code	84714100
Packaging data
Cables included	AC, LAN (RJ-45)
Other features
Certification	FCC CE BSMI VCCI RCM UKCA EAC KC UL
