Synology DiskStation DS2422+ NAS/storage server Tower Ryzen Embedded V1500B 4 GB DDR4 0 TB DiskStation Manager Black

AMD Ryzen V1500B, 4 GB DDR4, 12x SATA HDD, 4x RJ-45, 2x USB 3.2, 270x300x340 mm

Key Features

• AMD Ryzen Quad-core 2.2 GHz
• 2,201/1,383 MB/s sequential read read/write throughput
• Easily add 10/25GbE and NVMe SSD cache
• Expand to 24 bays with one DX1222 expansion unit

Reasons To Buy

Data Protection

Keep your business safe from data loss and minimize service downtime.

User Management

Manage user accounts and devices throughout your business with powerful directory services.

Security

Shield your Synology NAS from the most sophisticated threats with industry-leading security solutions.

Description

Built for high-performance mass storage
The 12-bay Synology DiskStation DS2422+ is a capable choice for small and medium businesses with large storage, file sharing, and data protection requirements in a multi-user environment. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video and as VM storage.

Faster performance
Comfortably run demanding applications and processes with multiple users on the DS2422+ while still enjoying a smooth and fast experience. See the improvements that help make your business productive.

Rise to the challenge
Prepare your DS2422+ for heavy workloads or upgrade flexibly as your business continues to grow. Use add-in cards to add bandwidth, fast SSD cache, or both.

Ready for remote work
Empower your workforce to collaborate, share files, and communicate from anywhere.

Certified virtual machine storage
DSM streamlines provisioning for and management of virtual machines with full certification for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack virtualization environments.

Synology Storage Console for VMware® or Windows platforms lets you manage storage directly from your hypervisor. VMware® VAAI integration and Windows ODX help offload storage operations and speed up data transfer, and a Kubernetes CSI driver lets you provision and manage volumes directly from the K8s CLI.

Specifications

Storage
Total installed storage capacity	0 TB
Storage drives installed	No
Installed storage drive type	No
Number of storage drives installed	0
Supported storage drive types	HDD & SSD
Number of storage drives supported	12
Maximum supported storage capacity	108 TB
Storage drive capacity	0 GB
Hot-swap drive bays	Yes
RAID support	Yes
Supported file systems	BTRFS, Fat, HFS+, NTFS, ext3, ext4
RAID levels	0, 5, 6, 10, JBOD
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported	2.5,3.5"
Processor
Processor generation	AMD Ryzen Embedded V1000 Series
Processor manufacturer	AMD
Processor frequency	2.2 GHz
Processor family	Ryzen Embedded
Processor model	V1500B
Processor cores	4
Number of processors supported	1
Memory
Internal memory type	DDR4
Internal memory	4 GB
Maximum RAM supported	32 GB
Memory slots	2
Memory form factor	SO-DIMM
ECC	Yes
Network
Link aggregation	Yes
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Wake-on-LAN ready	Yes
Supported network protocols	SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express x8 (Gen 3.x) slots	1
Ethernet LAN (RJ-45) ports	4
Hard drive
RAID support	Yes
Supported file systems	BTRFS, Fat, HFS+, NTFS, ext3, ext4
RAID levels	0, 5, 6, 10, JBOD
Design
Fan diameter 2	12 cm
Cooling type	Active
Fan diameter	12 cm
Drive bay locking	Yes
Product colour	Black
Number of fans	2 fan(s)
Chassis type	Tower
Technical details
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, iSCSI LUN
Product colour	Black
Noise level	25 dB
Multilingual support	Yes
Chassis type	Tower
Number of fans	2 fan(s)
Harmonized System (HS) code	84714100
Compliance certificates	RoHS
Performance
Browser supported	Chrome, Firefox, Edge, Internet Explorer, Safari
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, iSCSI LUN
Web-based management	Yes
Operating system installed	DiskStation Manager
Noise level	25 dB
Multilingual support	Yes
Access Control List (ACL)	Yes
Cooling
Cooling type	Active
Fan diameter	12 cm
Number of fans	2 fan(s)
Security
Drive bay locking	Yes
Access Control List (ACL)	Yes
Software
Operating system installed	DiskStation Manager
Management features
Web-based management	Yes
Power
Power consumption (HDD standby)	32.12 W
Power supply location	Built-in
Power supply unit (PSU) capacity	550 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	73.11 W
Number of power supply units	1
Weight & dimensions
Width	300 mm
Depth	340 mm
Height	270 mm
Weight	9.5 kg
Packaging content
Cables included	AC, LAN (RJ-45)
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Certificates
Certification	FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Logistics data
Harmonized System (HS) code	84714100
Packaging data
Cables included	AC, LAN (RJ-45)
Other features
Certification	FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Compliance certificates	RoHS
