QNAP TS-464 NAS Tower Intel® Celeron® N5095 8 GB DDR4 8 TB HDD QNAP Turbo System Black, Gold

Intel Celeron N5095, 8GB DDR4, 4GB Flash, 4x 2.5/3.5" SATA, 2x M.2, 2.5G LAN, USB, HDMI + 4x ST2000VN003

Key Features

• TS-464 is as fast as a single-port 10GbE NAS with up to 589 MB/s transfer speeds by setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports
• Perform additional tasks, stream more media, and have more services running with an Intel® quad-core processor optimized for multitasking
• Built-in GPU for enhanced video conversion, allowing videos to be smoothly streamed from the NAS to mobile devices
• Futureproof your network connection by installing a PCIe dual-port 10GbE network card that delivers up to 1,647 MB/s transfer speed
• Two USB 3.2 Gen 2 (10Gbps) ports allow faster backup to/from USB devices
• If two M.2 slots aren’t enough, install a QM2 PCIe expansion card for more M.2 SSD slots

Description

TS-464 is a compact 4-bay NAS with superior performance. Supporting up to 66 TB storage and 4 TB M.2 SSD caching* at an affordable price, the TS-464 fulfills your multitasking challenges for file management, backup, collaboration, and video conversion.

2.5GbE NAS is a must in 2024
With increasing availability on switches, motherboards, and laptops, 2023 is the year of 2.5GbE. The 2.5GbE TS-464 NAS is as fast as a single-port 10GbE NAS. By setting port trunking with the two built-in 2.5GbE (2.5G/1G/100M) ports to unleash network potential and increase fault tolerance, TS-464 delivers up to 589 MB/s transfer speeds.

Upgrade to dual-port 10GbE with a PCIe network card
With a superior hardware design, you can install a dual-port 10GbE network card QXG-10G2TB in the TS-464. Combining 10GbE networking, quad-core processor, and M.2 SSD caching, the TS-464 unleashes its full performance potential.

Expand storage capacity up to 16 hard drives
TS-464 supports a storage capacity of up to 66 TB by installing four 3.5-inch 22 TB hard drives in RAID 5. By connecting a TL-D1600S QNAP storage expansion unit, you can add an additional twelve hard drives to the TS-464 to achieve up to 280TB storage space to meet growing storage requirements.

Accelerate AI–powered image recognition and caching with TPU and PCIe expansion
TS-464 has two M.2 PCIe Gen 3 slots for installing NVMe SSD (including Apacer®, Micron®, Seagate®, WD®, and more) or Edge TPU.

Install M.2 NVMe SSDs for cache acceleration or efficient tiered storage
If you have a huge number of small files requiring read/write operations, you can easily boost IOPS of TS-464 by configuring its two M.2 SSDs as a cache disk.

When transmitting bigger files, you can create a storage pool with two M.2 SSDs. With Qtier automatically moving hot data to SSD and cold data to hard drives, TS-464 allows you to enjoy exceptional application performance.

Accelerate AI–powered image recognition with TPU
By leveraging a Edge TPU to QNAP AI Core (the AI-powered engine for image recognition), the TS-464 can perform high-speed face and object recognition. Edge TPU enables QuMagie to quickly process thousands of photos with high-speed AI Image recognition and classification, and QVR Face to analyze real-time video for instant facial recognition.

Abundant I/O capabilities with PCIe expansion
QNAP offers a wide range of expansion cards to add versatile functions to your NAS. The TS-464 has one PCIe Gen 3 x2 slot that supports various expansion cards for expanding application potential.

One Touch Copy backup with USB 3.2 Gen 2
TS-464 provides two 10Gbps USB 3.2 Gen 2 ports for faster file transfer to/from USB 3.2 Gen 2 devices. The One Touch Copy button also allows you to back up the contents of USB devices to the TS-464 with a single button press.

Smoother mobile experience with GPU
Taking a lot of photos with your smartphone? Qfile mobile app will help you free up space by automatically backing up photos to the TS-464. With Intel® UHD Graphics, the TS-464 greatly speeds up converting videos to 1080p / 720p, allowing for smooth streaming to mobile devices over varying mobile network speeds.

Use your NAS like a PC
QNAP’s exclusive Virtualization Station enables running multiple Windows®/Linux® virtual machines. By connecting a keyboard, mouse, and HDMI™ monitor, you can easily use the TS-464 as a PC.

QTS 5, Fast, smooth, and easy-to-use!
The TS-464 comes with the QTS 5 operating system as standard, providing a next-generation usage experience with an updated system kernel, optimized user interface, and advanced security features.
Brighter. Smoother. You’ll like it.
When navigating QTS 5, you will notice a finer attention to detail for a superior browsing experience. Enjoy a smoother NAS experience, comfortable visual design, and find your favorite apps quicker.
Get started with the notice board
When performing first-time installation, the notice board guides you through the setup process. Simply follow the step-by-step instructions for a quick and easy setup.
Smooth and reactive user interface
Whether clicking buttons, switching between apps, expanding/collapsing windows – every action is much smoother. The search bar in the main menu also assists in quickly finding desired apps.

All-in-one solution for hosting virtual machines and containers
By running multiple virtual machines and containers on the TS-464, you can deploy multi-tenant environments and applications to increase management efficiency and save hardware costs. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.

Enhanced cybersecurity and data protection
TS-464 is loaded with comprehensive privilege settings and security measures. Besides, there are abundant apps that help ensure optimal NAS protection against threats like malware and hackers.

A health check for your hard drives
Hard drives are at the heart of your NAS, and ensuring their long-term health and reliability is absolutely crucial. QNAP provides various methods and tools to help you monitor hard drive health, ensuring that you can take proactive decisions to safeguard your data and files.

Specifications

Storage
Total installed storage capacity	8 TB
Online RAID migration	Yes
Online RAID expansion	Yes
Disk roaming	Yes
Storage drives installed	Yes
Installed storage drive type	HDD
Number of storage drives installed	4
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Storage drive capacity	2 TB
Hot-swap drive bays	Yes
RAID support	Yes
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Supported storage drive interfaces	Serial ATA III
Storage drive sizes supported	2.5,3.5,M.2
Number of M.2 (M & B) slots	2
RAID rebuild	Yes
Processor
Processor manufacturer	Intel
Processor threads	4
Processor boost frequency	2.9 GHz
On-board graphics card model	Intel® UHD Graphics
CPU configuration (max)	1
Processor frequency	2 GHz
Processor family	Intel® Celeron®
Processor model	N5095
Processor cores	4
Number of processors supported	1
Memory
Internal memory type	DDR4
Internal memory	8 GB
Maximum RAM supported	8 GB
Flash memory	4000 MB
Network
Dynamic DNS (DDNS)	Yes
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,2500 Mbit/s
Wake-on-LAN ready	Yes
Jumbo frames support	Yes
iSCSI support	Yes
DHCP server	Yes
Ports & interfaces
USB port	Yes
HDMI version	2.1
USB 2.0 ports quantity	2
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
Concurrent connections	1500
PCI Express x2 (Gen 3.x) slots	1
Hard drive
RAID support	Yes
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Graphics
On-board graphics card model	Intel® UHD Graphics
Design
Cooling type	Active
Fan diameter	12 cm
Cable lock slot type	Kensington
Product colour	Black, Gold
Number of fans	1 fan(s)
LED indicators	HDD, LAN, Power, Status, USB
Chassis type	Tower
Cable lock slot	Yes
Technical details
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, USB drive, iSCSI LUN
Product colour	Black, Gold
Number of users	4096 user(s)
Multilingual support	Yes
LED indicators	HDD, LAN, Power, Status, USB
Chassis type	Tower
Buzzer	Yes
Number of fans	1 fan(s)
Performance
Built-in FTP server	Yes
System log	Yes
Share folder access right management	Yes
Share folder	AFP, CIFS/SMB, FTP
S.M.A.R.T. support	Yes
Hot spare	Yes
Disk scan	Yes
Browser supported	Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Backup button	Yes
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud, USB drive, iSCSI LUN
On/off switch	Yes
Windows operating systems supported	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	Solaris 10
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Security algorithms	FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH
Reset button	Yes
Operating system version	5.1.3
Operating system installed	QNAP Turbo System
Number of users	4096 user(s)
Multilingual support	Yes
Management protocols	SNMP
Buzzer	Yes
Access Control List (ACL)	Yes
Snapshot	Yes
USB copy function	Yes
Cooling
Cooling type	Active
Fan diameter	12 cm
Fan voltage	12 V
Number of fans	1 fan(s)
Security
Cable lock slot type	Kensington
Security algorithms	FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH
Cable lock slot	Yes
Access Control List (ACL)	Yes
Software
Windows operating systems supported	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	Solaris 10
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Operating system version	5.1.3
Operating system installed	QNAP Turbo System
Management features
On/off switch	Yes
Reset button	Yes
Management protocols	SNMP
Power
Power consumption (HDD standby)	21.618 W
Power supply location	External
Power supply unit (PSU) capacity	90 W
Fan voltage	12 V
AC input voltage	100 - 240 V
Power consumption (typical)	40.536 W
Number of power supply units	1
External power adapter	Yes
Weight & dimensions
Width	170 mm
Depth	226.5 mm
Height	165 mm
Packaging content
Number of screws	24
External power adapter	Yes
Cables included	AC, LAN (RJ-45)
Power cables quantity	1
Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Trusted Execution Technology	No
Intel 64	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
System requirements
Windows operating systems supported	Yes
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported	Solaris 10
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Operational conditions
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%
Packaging data
Cables included	AC, LAN (RJ-45)
