Synology RackStation RS822+ NAS Rack (1U) Ryzen Embedded V1500B 2 GB DDR4 48 TB HDD DSM Black

AMD Ryzen V1500B, 4 x 3.5" or 2.5" SATA HDD/SSD, 1U, 2 GB DDR4 ECC SODIMM, 2x USB 3.2 Gen 1 ports, 4x 1GbE RJ-45

Key Features

• 2103/1074 MB/s sequential read/write throughput
• Scale up to 8 drives with Synology Expansion Unit RX418
• Built-in 4 x 1GbE ports with 10/25 GbE expansion option
• Up to 32 GB DDR4 ECC

Description

An all-in-one edge storage solution
The compact 1U 4-bay Synology RackStation RS822+/RS822RP+ with its storage and connectivity expandability coupled with the powerful Synology DiskStation Manager (DSM) operating system is an ideal edge storage solution for branch offices and small and medium-sized businesses.

Built for reliability
RS822+ comes with four Gigabit RJ-45 ports which can be bonded with Link Aggregation to enable automatic network failover and load balancing.

Two RS822+ units can be paired using Synology High Availability to form a reliable active/passive server cluster, maximizing service uptime.

All-in-one data management platform
The RS822+ is designed to support small deployments in tackling common applications such as file management, data backup, and surveillance.

Edge storage for distributed teams
Provide secure and convenient multi-platform file access, sharing, and synchronization across different locations.

Multi-endpoint data protection
Design an effective backup strategy to maximize system availability with a host of native and license-free solutions.

Smart surveillance for small deployments
Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.

Powered by Synology DSM
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based DSM operating system.

Specifications

Storage
Total installed storage capacity	48 TB
Storage drives installed	Yes
Installed storage drive type	HDD
Number of storage drives installed	4
Supported storage drive types	HDD & SSD
Number of storage drives supported	4
Storage drive interface	Serial ATA
Storage drive capacity	12 TB
Storage drive size	2.5/3.5"
Hot-swap drive bays	Yes
RAID support	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Supported storage drive interfaces	Serial ATA
Storage drive sizes supported	2.5,3.5"
Processor
Processor generation	AMD Ryzen Embedded V1000 Series
Processor manufacturer	AMD
Processor threads	8
Processor frequency	2.2 GHz
Processor family	Ryzen Embedded
Processor model	V1500B
Processor cores	4
Memory
Internal memory type	DDR4
Internal memory	2 GB
Maximum RAM supported	32 GB
Memory form factor	SO-DIMM
ECC	Yes
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wake-on-LAN ready	Yes
Supported network protocols	SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, and VPN (PPTP, OpenVPN™, L2TP)
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
PCI Express x8 (Gen 3.x) slots	1
Ethernet LAN (RJ-45) ports	4
eSATA ports quantity	1
Hard drive
RAID support	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
RAID levels	0, 1, 5, 6, 10, JBOD
Design
Fan diameter 2	4 cm
Cooling type	Active
Fan diameter	4 cm
Built-in display	No
Product colour	Black
Number of fans	3 fan(s)
LED indicators	Yes
Chassis type	Rack (1U)
Technical details
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud
Built-in display	No
Product colour	Black
Number of users	2048 user(s)
Noise level	27.4 dB
LED indicators	Yes
Chassis type	Rack (1U)
Number of fans	3 fan(s)
Sustainability compliance	Yes
Compliance certificates	RoHS
Performance
Type	NAS
Device class	Small & Medium Business
Backup function	Yes
Backup features	Cloud
On/off switch	Yes
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Security algorithms	HTTPS, SSH, SSL/TLS
Reset button	Yes
Operating system installed	DSM
Number of users	2048 user(s)
Noise level	27.4 dB
Access Control List (ACL)	Yes
Cooling
Cooling type	Active
Fan diameter	4 cm
Number of fans	3 fan(s)
Security
Security algorithms	HTTPS, SSH, SSL/TLS
Access Control List (ACL)	Yes
Software
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Operating system installed	DSM
Management features
On/off switch	Yes
Reset button	Yes
Power
Power consumption (HDD standby)	16.7 W
Power supply location	Built-in
Power supply unit (PSU) capacity	150 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	47.69 W
Weight & dimensions
Width	430.5 mm
Depth	457.6 mm
Height	44 mm
Weight	6.4 kg
Packaging content
Cables included	AC
Sustainability
Sustainability compliance	Yes
System requirements
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	8 - 80%
Operating altitude	0 - 5000 m
Certificates
Certification	FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Packaging data
Cables included	AC
Other features
Certification	FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Compliance certificates	RoHS
