ENDORFY Supremo FM5 Gold 1000 W power supply unit 18+10 pin ATX ATX Black

Supremo FM5 Gold 1000 W

Description

The Supremo FM5 Gold 1000 W is like "God Mode" for your computer. It is a mighty power supply with a DC-DC topology that gives you tight voltage regulation, stable operation, and a continuous power delivery of 1000 W. This means that it can handle even the most demanding components with ease and will protect you against unexpected reboots and blue screens. Because your screen is made for more colors than just blue;)

We’ve packed the Supremo FM5 Gold 1000 W with everything we think is best. No wonder our power supply has been certified 80 PLUS® Gold :)

For example, you get the 12 cm Fluctus PSU 120 mm fan to keep your power supply cool. The Supremo FM5 Gold 1000 W is also small – it’s only 14 cm long. That's enough to fit it into smaller enclosures (especially since you can disconnect the unnecessary cables).

Stable on every line
Every technology hero experiences their own “rise of the machines” from time to time – like reboots or blue screens. With the Supremo FM5 Gold 1000 W, you’re always safe and never sorry. We’ve designed it to maintain a stable voltage on each line separately. As a result, your computer works perfectly even with the most demanding components.

That sounds good quiet!
When you’re working with top components, you need a power supply that can easily keep up with their requirements (and yours too). Enter the Supremo FM5 Gold 1000 W – all in white black. It is a powerful device that keeps up with the pace of your work without even a squeak any kind of hum. It never overheats or makes a noise even when you’re rendering 3D projects or encoding video from dawn till dusk.

Japanese capacitors only (no katanas, but still sharp)
The Supremo FM5 Gold 1000 W is a power supply that can easily handle the most hardcore temperatures. Where the water starts to boil, this PSU keeps its cool – it can work even at 105° Celsius.

7-year warranty
The Supremo FM5 Gold 1000 W is covered by an extended, 7-year warranty. You probably won’t need to use it anyway (hello, it’s ENDORFY!), but it’s still nice to have it.

Specifications

Cooling
Fan diameter	12 cm
Number of fans	1 fan(s)
Fan speed	250 - 1400 RPM
Performance
On/off switch	Yes
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Gold
Purpose	PC
Mean time between failures (MTBF)	100000 h
Supported motherboard form factors	ATX
Design
80 PLUS certification	80 PLUS Gold
Product colour	Black
Fan diameter	12 cm
On/off switch	Yes
Number of fans	1 fan(s)
Fan speed	250 - 1400 RPM
Power
Total power	1000 W
AC input voltage	115 - 230 V
Combined power (+3.3V)	100 W
Combined power (+12V)	996 W
Combined power (+5V)	100 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	83 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Power protection features	Over power, Over voltage, Under voltage, Over current, Short circuit
Ports & interfaces
Motherboard power connector	18+10 pin ATX
Number of SATA power connectors	3
PCI Express power connectors (8-pin)	6
Cabling type	Fully-Modular
Packaging content
Cables included	AC
Weight & dimensions
Width	140 mm
Depth	150 mm
Height	87 mm
Packaging data
Cables included	AC
Certificates
80 PLUS certification	80 PLUS Gold
