Dell Universal Docking Station | UD22

2 x DisplayPort, 1 x HDMI, 4 x USB-C 3.2 Gen 2,2 x USB-C 3.2 Gen 2, RJ-45, Black

Reasons To Buy

Universal connectivity

Consistent experience
Connect to any USB-C notebook, regardless of the manufacturer, and run any operating system.

Multiple monitor support
Enhance your coworking spaces with consistent display support across different systems.

High power delivery
Achieve a fast-charging experience with up to 96W power delivery for any USB-C notebook.

Next-level productivity

Enhanced display support
Maximize productivity with the highest number of displays supported on a universal dock, enabling connection of up to four 4K monitors via DisplayLink drivers.

Multiple ports
With the highest number of ports on a universal dock, create a productive work station with increased flexibility.

Seamless experience and supportive management

Faster, easier deployment
Connect your laptop and get started quickly even when the DisplayLink driver is not installed, thanks to the additional support for DP Alt mode.

Hoteling made convenient
Enhance the shared workspace experience further with DisplayLink’s layout provisioning feature that enables preconfigured display layout automatically for the users.

Extended warranty
Dell Docks now have their own service tags, along with a 3 to 5 year warranty option for the best support, management and upgradeability possible.

Description

Experience the ultimate universal dock, equipped with 10 ports, for any USB-C notebook.

Specifications

Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	2
Host interface	USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.0
DisplayPorts quantity	2
Microphone in	No
DC-in jack	Yes
Connectivity technology	Docking
USB Power Delivery (USB PD)	Yes
USB Power Delivery revision	3.0
PowerShare	Yes
Number of USB ports with PowerShare support	2
USB Power Delivery up to	96 W
DisplayPort version	1.4
USB Type-C DisplayPort Alternate Mode	Yes
Network
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Maximum digital resolution	5120 x 2880 pixels
Product colour	Black
Card reader integrated	No
Cable lock slot	Yes
LED indicators	Yes
Cable lock slot type	Kensington
VESA mounting	Yes
Maximum VESA mount	100 x 100 mm
Technical details
Product colour	Black
Cable lock slot	Yes
Harmonized System (HS) code	84733020
Storage
Card reader integrated	No
Power
Power source type	DC
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Output voltage	19.5 V
Output current	6.67 A
Power supply	130 W
Software
Windows operating systems supported	Windows 10, Windows 11
Mac operating systems supported	MacOS
Linux operating systems supported	Ubuntu 20.04 LTS
Other operating systems supported	ChromeOS
Indication
LED indicators	Yes
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 90%
Weight & dimensions
Weight	416 g
Width	76 mm
Depth	166 mm
Height	32 mm
Design
Windows operating systems supported	Windows 10, Windows 11
Mac operating systems supported	MacOS
Product colour	Black
Cable lock slot	Yes
LED indicators	Yes
Cable lock slot type	Kensington
Packaging content
Quick start guide	Yes
Cables included	USB Type-C
AC adapter included	Yes
Logistics data
Harmonized System (HS) code	84733020
