Lenovo

Lenovo ThinkCentre M70q Gen 5 Intel® Core™ i5 i5-14400T 8 GB DDR5-SDRAM 256 GB SSD Windows 11 Pro Mini PC Black

SKU 12TD003QUK
£511.62
£511.62
Excluding taxes
Intel Core i5-14400T, 10C (6P + 4E)/16T, P-core 1.5/4.5GHz, E-core 1.1/3.2GHz, 20MB, 1x 8GB SO-DIMM DDR5-4800, 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal, Intel UHD Graphics 730, Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT5.3 vPro, Windows 11 Pro

Key Features

  • Intel Core i5-14400T, 10C (6P + 4E)/16T, P-core 1.5/4.5GHz, E-core 1.1/3.2GHz, 20MB
  • 1x 8GB SO-DIMM DDR5-4800
  • 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal
  • Intel UHD Graphics 730
  • Windows 11 Pro

Description

Big Performance in a Compact PC
- High-performing business desktop that fits anywhere, even horizontally positioned
- Optimized workloads with up to Intel® Core™ performance
- Fast data processing with dual-channel memory
- Enhanced privacy & enterprise-grade security

Specifications

Processor
Processor generation Intel® Core™ i5 (14th gen)
Processor cache type Smart Cache
Processor cache 20 MB
Processor model i5-14400T
Number of processors installed 1
Processor manufacturer Intel
Processor boost frequency 4.5 GHz
Processor threads 16
Processor cores 10
Processor family Intel® Core™ i5
Performance cores 6
Efficient cores 4
Performance-core base frequency 1.5 GHz
Efficient-core base frequency 1.1 GHz
Processor base power 35 W
Maximum turbo power 82 W
Efficient-core Max Turbo Frequency 3.2 GHz
Performance-core Max Turbo Frequency 4.5 GHz
Memory
Non-ECC Yes
ECC No
Memory layout (slots x size) 1 x 8 GB
Internal memory 8 GB
Maximum internal memory 64 GB
Memory slots 2x DIMM
Internal memory type DDR5-SDRAM
Memory clock speed 4800 MHz
Memory channels Dual-channel
Storage
Storage media SSD
Number of storage drives installed 1
Optical drive type No
SSD interface PCI Express 4.0
SSD capacity 256 GB
Number of SSDs installed 1
Card reader integrated No
Total storage capacity 256 GB
SSD form factor M.2
Total SSDs capacity 256 GB
NVMe Yes
M.2 SSD size 2280 (22 x 80 mm)
Graphics
Discrete graphics card No
On-board graphics card family Intel® UHD Graphics
On-board graphics card Yes
Discrete graphics card model Not available
On-board graphics card model Intel UHD Graphics 730
On-board GPU manufacturer Intel
Optical drive
Optical drive type No
Network
Ethernet LAN Yes
Wi-Fi Yes
Bluetooth Yes
Bluetooth version 5.3
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Ethernet LAN data rates 100,1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
WLAN controller model Intel Wi-Fi 6E AX211
Top Wi-Fi standard Wi-Fi 6E (802.11ax)
Antenna type 2x2
WLAN controller manufacturer Intel
Ports & interfaces
Combo headphone/mic port Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 0
Thunderbolt 3 ports quantity 0
HDMI version 2.1
USB 2.0 ports quantity 1
HDMI ports quantity 1
Ethernet LAN (RJ-45) ports 1
DisplayPorts quantity 1
M.2 card slot (wireless) 1
M.2 card slot (storage) 2
DisplayPort version 1.4a
Number of rear USB ports 4
Number of front USB ports 3
Number of front audio ports 1
Technical details
Cable lock slot type Kensington
Product type Mini PC
Trusted Platform Module (TPM) Yes
Product colour Black
Chassis type Mini PC
Audio system High Definition Audio
Cable lock slot Yes
Motherboard chipset Intel Q670
Sustainability certificates ENERGY STAR, EPEAT Silver, ErP, GREENGUARD, TCO
Compliance certificates RoHS
Design
VESA mounting Yes
Volume 1 L
Cable lock slot type Kensington
Product colour Black
Chassis type Mini PC
Cable lock slot Yes
Colour name Black
Performance
Audio chip Realtek ALC233VB
Number of speakers 1
Password protection Yes
Password protection type BIOS, HDD, Power on, Supervisor
Product type Mini PC
Trusted Platform Module (TPM) Yes
Audio system High Definition Audio
Built-in speaker(s) Yes
Motherboard chipset Intel Q670
Trusted Platform Module (TPM) version 2.0
Software
Operating system language English
Operating system architecture 64-bit
Operating system installed Windows 11 Pro
Power
Power supply input frequency 50/60 Hz
Power supply input voltage 100 - 240 V
Power supply 90 W
Operational conditions
Operating altitude 0 - 3048 m
Storage temperature (T-T) -40 - 60 °C
Operating relative humidity (H-H) 20 - 80%
Storage relative humidity (H-H) 10 - 90%
Operating temperature (T-T) 5 - 35 °C
Non-operating altitude 0 - 12192 m
Certificates
Certification ENERGY STAR,TCO,EPEAT Silver,RoHS
Compliance certificates RoHS
Sustainability
Sustainability certificates ENERGY STAR, EPEAT Silver, ErP, GREENGUARD, TCO
Ergonomics
VESA mounting Yes
Weight & dimensions
Volume 1 L
Package width 490 mm
Package depth 128 mm
Package height 250 mm
Width 179 mm
Depth 182.9 mm
Height 36.5 mm
Package weight 3.2 kg
Weight 1.25 kg
Packaging data
Package width 490 mm
Package depth 128 mm
Package height 250 mm
Package weight 3.2 kg
Packaging content
Mouse included Yes
Display included No
Keyboard included Yes
Mouse connectivity Wired
Keyboard connectivity Wired
Display
Display included No
Other features
VESA mounting Yes
Number of speakers 1
Trusted Platform Module (TPM) Yes
On-board graphics card Yes
Processor manufacturer Intel
Built-in speaker(s) Yes
