DrayTek Vigor 2865ax | Dual-band 2.4 GHz / 5 GHz | Wi-Fi 6 802.11ax | 800 Mbit/s WLAN data rate | Gigabit Ethernet | 10/100/1000 Mbit/s | Tabletop router | White | External antenna | 1x1 | RP-SMA connector| Power source AC/DC | 100–240V input | 12V output

Vigor 2865ax VDSL router with Wi-Fi 6 AX3000 wireless

Key Features

• VigorACS SD-WAN Central Management
• 5+1 Gigabit LAN Ports with VLANs
• Robust SMB VPN Router
• Packed With Features
• Wi-Fi 6 - AX3000 Performance
• VDSL and Ethernet Load Balancer

Description

The Ideal DSL Router with VPN for Small Business and Remote Working
DrayTek’s Vigor 2865 series Multi-WAN Firewall VPN routers are ideal for Superfast VDSL Broadband and Ethernet-based FTTP Fibre Broadband. With Gigabit throughput, Quality of Service, VPN client/server, comprehensive Firewall and Content Filtering controls.

Options for Wi-Fi 6 on ‘ax’ models, or Wi-Fi 5 ‘ac’ models provide fast & efficient wireless connectivity, while the integrated 4G+ LTE modem on ‘Lac’ models takes full advantage of mobile broadband. The Vigor 2865 series provides a reliable, flexible, and secure networking solution, that’s ideal for Home Offices, Small Business and Satellite Offices.

VDSL and Ethernet Load Balancer
Connect the Vigor 2865ax to Superfast Fibre with the integrated VDSL modem. Use the Ethernet WAN with Cable and Ultrafast FTTP. Load Balance multiple connections to boost performance.

Wi-Fi 6 - AX3000 Performance
Wi-Fi 6 wireless provides gigabit Wi-Fi with reliable throughput. Ideal for time-sensitive video conferencing, low latency gaming and handling 4K Ultra-HD streaming, without buffering.

Packed With Features
Take advantage of DrayTek’s rich feature set and useful functionality such as Quality of Service, Route Policy, VPN Matcher, DrayDDNS and more.

Robust SMB VPN Router
Quickly and securely connect remote sites with up to 32 VPN tunnels. Enable remote workers to access resources with DrayTek SSL VPN and OpenVPN support.

5+1 Gigabit LAN Ports with VLANs
Link Server, Computers, and Network Attached Storage directly, with up to 6 Gigabit LAN ports. VLANs allow for as many as 8 separate networks, with options for Hotspot Captive Portal.

VigorACS SD-WAN Central Management
Manage the Vigor 2865 remotely and utilise DrayTek’s powerful SD-WAN features with the VigorACS 3 management platform. Centrally manage & provision whole networks across multiple sites.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
DSL features
DSL WAN	Yes
ADSL2	Yes
VDSL	Yes
Mobile network
SIM card slot	No
3G/4G USB modem compatibility	No
Network
Network address translation (NAT)	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wireless Distribution System (WDS) bridge	Yes
Policy-based routing	Yes
WAN connection
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	No
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	800 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ports & interfaces
USB port	Yes
USB 2.0 ports quantity	2
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Management features
Web-based management	Yes
Security
Network address translation (NAT)	Yes
Firewall	Yes
Protocols
DHCP server	Yes
DHCP client	Yes
Design
Product type	Tabletop router
Wall mountable	Yes
On/off switch	Yes
Product colour	White
Indication light	Yes
Packaging content
Quick start guide	Yes
Antenna included	Yes
Antenna
Antenna design	External
Antennas quantity	2
Antenna gain level (max)	5 dBi
Antenna connector type	RP-SMA
Antenna type	1x1
Power
Power source type	AC, DC
Power consumption (typical)	28.2 W
Output voltage	12 V
AC input voltage	100 - 240 V
Operational conditions
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	241 mm
Weight	780 g
Height	44 mm
Depth	165 mm
Packaging data
Quick start guide	Yes
Antenna included	Yes
