DrayTek Vigor 2763ac SoHo Router firewall | with 802 11ac Wi-Fi

VDSL2 / ADSL2+, RJ-11, Gigabit Ethernet (1G/100M/10M), RJ-45, USB 2.0 Port for 3G/4G Modem, 2x Removable Wireless antennas, 207 x 131 x 42mm, White

Key Features

• VigorACS Central Management
• 4 Gigabit LAN Ports with VLANs
• Powerful SoHo VPN Router
• Packed With Features
• AC1300 Wireless with Mesh
• VDSL and Ethernet Router

Description

The Ideal SoHo VPN Router for VDSL and Gigabit Fibre The DrayTek Vigor 2763 series VDSL and Ethernet VPN routers are ideal for Small Office and Home Office networks. Featuring powerful Firewall and Content Filtering, configurable Quality of Service and an array of VPN capabilities, with the performance to make full use of FTTP Fibre Broadband. Incorporating Wireless in the Vigor 2763ac model, the Vigor 2763 series provide a reliable, highly integrated and reliable connectivity solution for SoHo networks. VDSL and Ethernet Router Connect the Vigor 2763 to Superfast Fibre with its integrated VDSL modem. Or connect to VirginMedia Cable and Ultrafast FTTP with Ethernet WAN. AC1300 Wireless with Mesh Connect DrayTek VigorAP Access Points to the router in a wireless Mesh. DrayTek’s Self-Optimising Mesh ensures access points are always connecting through the best path to your Router. Packed With Features Configure DrayTek’s rich feature set to fit your network with App level network management, Route Policy, Quality of Service, VPN Matcher, advanced 2-factor security, DrayDDNS and more. Powerful SoHo VPN Router Connect remote locations with 2 VPN tunnels for Remote Dial-In User Teleworker and Dial-Out LAN to LAN VPN. Up to 200Mbps IPsec performance, with SSL and OpenVPN support. 4 Gigabit LAN Ports with VLANs Allows Computers, Servers and Network Attached Storage to transfer at Gigabit speed. Up to 4 LAN subnets and VLANs allow you to keep Guest networks from accessing private network data. VigorACS Central Management DrayTek's powerful VigorACS central management platform allows you to manage, monitor and configure the Vigor 2763, along with all other DrayTek products remotely across multiple locations.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10000,100000 Mbit/s
DSL features
DSL WAN	Yes
ADSL2+	Yes
VDSL2	Yes
Mobile network
SIM card slot	No
3G/4G USB modem compatibility	Yes
Network
Network address translation (NAT)	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10000,100000 Mbit/s
Port triggering	Yes
Built-in FTP server	Yes
VPN Passthrough	Yes
Static route	Yes
Multicast support	Yes
Dynamic DNS (DDNS)	Yes
Protocols
DMZ support	Yes
Universal Plug and Play (UPnP)	Yes
DHCP server	Yes
Management features
Universal Plug and Play (UPnP)	Yes
WPS push button	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
Bandwidth control	Yes
MU-MIMO technology	Yes
WAN connection
Ethernet WAN	Yes
DSL WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	866 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Ports & interfaces
USB port	Yes
USB 2.0 ports quantity	2
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Security
URL filtering	Yes
Security algorithms	WEP, WPA, WPA2, WPA3
Network address translation (NAT)	Yes
Firewall	Yes
DMZ support	Yes
Authentication method	Pre-Shared Key
Filtering	Yes
Stateful Packet Inspection (SPI)	Yes
DDoS protection	Yes
Design
Product type	Tabletop router
Product colour	White
Packaging content
Quick start guide	Yes
Cables included	DC, LAN (RJ-45)
Quick installation guide	Yes
Antenna included	Yes
Antenna
Antenna design	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
Antenna type	1x1
Power
Power source type	DC
Power consumption (typical)	21 W
Output voltage	12 V
AC input voltage	100 - 240 V
Operational conditions
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	207 mm
Height	42 mm
Depth	131 mm
Packaging data
Quick start guide	Yes
Cables included	DC, LAN (RJ-45)
Quick installation guide	Yes
Antenna included	Yes
