ASUS TUF-BE3600 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

TUF Gaming BE3600 Dual Band WiFi 7 Gaming Router, Equipped with Powerful Broadcom SoC, Boasting Ultra-high Computational Speed, 3-step Port Forwarding, AiMesh for Mesh WiFi, and AiProtection Pro for Network Security

Key Features

• Ultrafast WiFi 7 – Next-generation WiFi 7 router boosts speeds up to 3600 Mbps
• 4K-QAM Modulation – All-new 4096-QAM offers a 1.2 times increase in transmission speed compared to the previous generation
• High Computational Power CPU – Equipped with the all-new Broadcom quad-core powerhouse CPU, boasting a DMIPS computational capability of 20K, effortlessly handling both software and hardware-related tasks
• ASUS AiMesh Support – Support AiMesh to create a whole-home mesh network
• Tested Durability and Stable Operation – TUF Gaming BE3600 is built to be durable and undergoes verified testing to ensure reliable, stable operation

Description

TUF Gaming BE3600
Inspired by the unique design and power wings of drones, the TUF Gaming BE3600 combines a sleek appearance with advanced cooling efficiency. Its hollow design on both sides enhances heat dissipation for stable all-day operation, enhancing your internet and gaming experience.

4K-QAM
Compared to 1024-QAM with WiFi 6/6E, 4096-QAM (Quadrature Amplitude Modulation)* allows each signal to more densely incorporate larger amounts of data, delivering up to 20% more efficient data transmission.

Multi-Link Operation (MLO)
Multi-Link Operation (MLO)* enables buffering-free connection by intelligently combining and switching between the 2.4 GHz and 5 GHz bands. TUF Gaming BE3600 is built to be future-proof with all WiFi 7 devices, regardless of the MLO mode they utilize*.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	1000 Mbit/s
Mobile network
SIM card slot	No
3G/4G USB modem compatibility	Yes
Network
Wake-on-LAN ready	Yes
Network address translation (NAT)	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
VPN support	VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion
Port forwarding	Yes
Ethernet LAN data rates	1000 Mbit/s
Port triggering	Yes
Number of guest networks (5 GHz)	3
Number of guest networks (2.4 GHz)	3
Support Samba (storage)	Yes
Built-in FTP server	Yes
VPN server	VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard
Dynamic DNS (DDNS)	Yes
Protocols
DMZ support	Yes
DHCP server	Yes
Security
VPN support	VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion
URL filtering	Yes
System event log	Yes
Security algorithms	SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Personal, WPS
Network address translation (NAT)	Yes
NAT functionality	NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
MAC address filtering	Yes
Firewall security	Maximum Firewall Keyword Filter : 64 • Maximum Firewall Network Service Filter : 32 • Maximum Firewall URL Filter : 64
Firewall	Yes
DMZ support	Yes
Parental control	Yes
Performance
Processor frequency	2000 MHz
Processor cores	4
Built-in processor	Yes
Internal memory	1000 MB
Flash memory	256 MB
Weight & dimensions
Package width	420 mm
Package weight	1.13 kg
Package height	90 mm
Package depth	190 mm
Width	274 mm
Weight	561 g
Height	205 mm
Depth	168 mm
Packaging content
Package type	Box
Number of products included	1 pc(s)
Quick start guide	Yes
Cables included	LAN (RJ-45)
AC adapter included	Yes
Warranty card	Yes
WAN connection
Ethernet WAN	Yes
SIM card slot	No
3G/4G USB modem compatibility	Yes
WAN connection type	RJ-45
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
WLAN data transfer rate (max)	2882 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Modulation	4096-QAM, OFDMA
WLAN data transfer rate (first band)	688 Mbit/s
WLAN data transfer rate (second band)	2882 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Ports & interfaces
USB port	Yes
Ethernet LAN (RJ-45) ports	5
DC-in jack	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Management features
WPS push button	Yes
Wake-on-LAN ready	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
Design
Product type	Tabletop router
On/off switch	Yes
LED indicators	LAN, Power, WAN
Product colour	Black
Other features
Internal memory	1000 MB
Flash memory	256 MB
Antenna
Antenna design	External
Antennas quantity	4
Features
Processor frequency	2000 MHz
Processor cores	4
Built-in processor	Yes
Internal memory	1000 MB
Flash memory	256 MB
Power
Power source type	AC
Output voltage	12 V
Output current	2 A
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Packaging data
Quick start guide	Yes
Package width	420 mm
Package weight	1.13 kg
Package type	Box
Package height	90 mm
Package depth	190 mm
Cables included	LAN (RJ-45)
AC adapter included	Yes
Warranty card	Yes
Number of products included	1 pc(s)
