Mercusys 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

300 Mbps (2.4 GHz), 867 Mbps (5 GHz), 802.11ac/a/b/g/n, 4G+, Nano SIM, 95x61.05x165.97 mm

Key Features

• 4G+ network – Enjoy the 4G+ Cat 6 download speeds up to 300 Mbps
• Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests
• Dual Band 1200 Mbps WiFi – Fast WiFi speeds up to 300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band
• Simultaneous Connection– Enjoy and share internet access with up to 64 Wi-Fi devices
• Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection

Description

Faster and Smoother
with 4G+ Speed and
Dual Band WiFi
4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

Plug Your Nano SIM Card and Play
Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide. Insert a nano SIM card and turn on the router to share your 4G LTE network with multiple Wi-Fi devices.

Get Wi-Fi Where You Need It
Enjoy unmatched convenience and versatility and the utilize fast and stable Wi-Fi, whether you're at home or working remote.

Extra Fast 4G+ Cat 6 Speed for Reliable Wi-Fi
MB230-4G supports the 4G+ Cat 6, which uses Carrier Aggregation technology, to achieve superfast LTE speeds up to 300 Mbps download and 50 Mbps upload. It can also share a dual band Wi-Fi network for gaming, streaming, and more.

Share the WiFi with Friends
An remarkable number of wireless gadgets are compatible with this 4G router without any issues. Up to 64 simultaneous connections for tablets, laptops, mobile phones, and other devices.

Full with Strong and Stable Signal
Internal high gain antennas strengthen the WiFi signal, extend the range of connection establishment, and boost the sensitivity of the router.

Available WAN Connection Backup
With a fully functional WAN/LAN port, MB230-4G can work as a router which is compatible with cable, fiber, and DSL modems, or provide internet for wired devices. The reliable access is for up to 64 devices Simultaneously.

Easy Setup and Management via MERCUSYS App
Set up and manage your Wi-Fi through the MERCUSYS app from your smartphone (Android, iOS).

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
DSL features
DSL WAN	No
Mobile network
SIM card slot	Yes
3G/4G USB modem compatibility	Yes
Mobile network generation	4G
4G bands supported	700,800,850,900,1800,2100,2300,2600 MHz
3G standards	HSPA, HSPA+, UMTS
4G standard	LTE-TDD & LTE-FDD
Dual SIM support	No
SIM card type	NanoSIM
3G bands supported	850,900,2100 MHz
Network
VoIP protocols	IPv4, IPv6
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Receiver sensitivity	11g 6Mbps: -95dBm; 11g 54Mbps: -77dBm; 11n HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm; 11a 6Mbps: -92dBm; 11a 54Mbps: -75dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65dBm; 11ac VHT80 MCS9: -61dBm
Port forwarding	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10,100,1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Port triggering	Yes
Dynamic DNS (DDNS)	Yes
Protocols
DMZ support	Yes
VoIP protocols	IPv4, IPv6
Universal Plug and Play (UPnP)	Yes
DHCP server	Yes
Management features
Universal Plug and Play (UPnP)	Yes
WPS push button	Yes
Reset button	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Performance
Firmware upgradeable	Yes
Packaging content
Package type	Box
Number of products included	1 pc(s)
AC adapter included	Yes
Quick installation guide	Yes
WAN connection
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	Yes
3G/4G USB modem compatibility	Yes
Dual SIM support	No
WAN connection type	RJ-45
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ports & interfaces
USB port	No
Ethernet LAN (RJ-45) ports	2
DC-in jack	Yes
Security
System event log	Yes
Security algorithms	64-bit WEP, WPA-PSK, WPA2-PSK, WPA3-SAE
Port-based Network Access Control (PNAC)	Yes
Firewall	Yes
DMZ support	Yes
Design
Product type	Desktop/pole router
Product colour	White
Indication light	Yes
Antenna
Antenna design	Internal
Features
Firmware upgradeable	Yes
Power
Power source type	DC
Output voltage	12 V
Output current	1 A
Operational conditions
Storage temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	95 mm
Height	166 mm
Depth	61 mm
Packaging data
Package type	Box
AC adapter included	Yes
Quick installation guide	Yes
Number of products included	1 pc(s)
