StarTech.com 1 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention

StarTech.com FTDI USB to Serial Adapter DB9 with COM Retention - USB to Serial RS232 Adapter - USB Serial Adapter - USB to Serial Adapter

Description

Add an RS232 serial port with COM retention to your laptop or desktop computer through USB

The ICUSB2321F 1-Port USB to Serial RS232 Adapter Cable with FTDI chipset and COM Retention converts an available USB 1.1 or 2.0 port into an RS232 serial DB9 port to connect, monitor and control your serial devices. This compact adapter features COM retention, allowing the same COM port value to automatically be re-assigned to the port if the cable is disconnected and re-connected to the host computer, or if the system is rebooted. The ICUSB2321F uses the FTDI chipset which supports additional customization, advanced features, and compatibility not necessarily offered by other solutions. Compatibility with a broad list of Operating Systems including Windows®, Windows CE, Mac OS and Linux, makes this product easy to integrate into mixed environments. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Specifications

Ports & interfaces
Connector 2	USB 2.0 A
Connector 1	DB-9
Cable length	0.2 m
Connector 2 gender	Male
Connector 1 gender	Male
Technical details
Product colour	Black
Cable length	0.2 m
Compliance certificates	RoHS
Design
Product colour	Black
Certification	CE, FCC
Cable length	0.2 m
Performance
Chipset	FTDI - FT232RL
Stop bits	1, 2
Data bits	7, 8
Baud rate	115.2 Kbit/s
FIFO (First In, First Out)	256 B
Compatible operating systems	Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x
Product colour	Black
Certification	CE, FCC
Parity bit	Even, Mark, No, Odd, Space
System requirements
Compatible operating systems	Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x
Certificates
Certification	CE, FCC
Operational conditions
Storage temperature (T-T)	-20 - 85 °C
Relative humidity	5 - 95%
Operating temperature (T-T)	0 - 55 °C
Weight & dimensions
Width	41.5 mm
Weight	90 g
Height	22 mm
Depth	45 mm
Packaging data
Package width	145 mm
Package height	32 mm
Package depth	175 mm
Package weight	176 g
Packaging content
Manual	Yes
Drivers included	Yes
Logistics data
Products per master (outer) case	80 pc(s)
Master (outer) case width	450 mm
Master (outer) case length	525 mm
Master (outer) case height	345 mm
