StarTech.com 1 Port Metal Industrial USB to RS422/RS485 Serial Adapter w/ Isolation

1 Port Metal Industrial USB to RS422/RS485 Serial Adapter w/ Isolation

Description

Add an R422/485 serial port to your laptop or desktop computer through USB

The ICUSB422IS 1 Port Metal Industrial USB to RS422/RS485 Serial Adapter w/ Isolation connects to a computer using USB and allows you to connect any RS-422 or RS-485 serial device via the provided DB9 port or hard-wired to the terminal block. The USB to serial adapter features circuit isolation to ensure that sensitive controls and devices will not be damaged while connected, making it a viable solution for connecting costly industrial serial devices. The RS422/485 Converter receives full power via the host USB connection, and provides power to the attached serial device without requiring an external power adapter. Designed to provide a durable serial solution, the USB to RS422/485 Converter is ruggedly constructed and can be mounted nearly anywhere. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

Specifications

Ports & interfaces
Connector 2	RS-422/485
Connector 1	USB B
Cables included	USB
Cable length	1.8 m
Connector 2 gender	Female
Connector 1 gender	Male
Technical details
Input voltage	5 V
Product colour	Black
Cable length	1.8 m
Design
Product colour	Black
Cable length	1.8 m
Performance
Input voltage	5 V
Compatible operating systems	Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x+
Product colour	Black
Data transfer rate	0.00088 Gbit/s
System requirements
Compatible operating systems	Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11 Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, 13.0 Linux Kernel 3.0.x+
Power
Input voltage	5 V
Operational conditions
Storage temperature (T-T)	-20 - 85 °C
Relative humidity	5 - 95%
Operating temperature (T-T)	0 - 55 °C
Weight & dimensions
Width	64 mm
Weight	180 g
Height	23 mm
Depth	118 mm
Packaging data
Package width	45 mm
Package height	160 mm
Package depth	230 mm
Package weight	390 g
Packaging content
Cables included	USB
Quantity per pack	1 pc(s)
Logistics data
Products per master (outer) case	50 pc(s)
Master (outer) case width	502 mm
Master (outer) case length	400 mm
Master (outer) case height	511 mm
