Epson ELPDC07

ELPDC07

Key Features

• Clear, smooth images: Full HD 1080p camera and 30-frames-per-second screen refresh rate
• Capture every detail: 8x digital zoom, one-touch auto focus and freeze function
• Simple to connect: Two-in-one USB cable connection, no need for a separate power supply
• Flexible for 2D visuals and 3D objects: Adjustable height, 90º head rotation and microscope attachment
• Lightweight and portable: Portable design weighs less than 1Kg and a soft carry case included

Description

Portable visualiser
Let a wide audience get up close to your source material with the Epson ELPDC07 visualiser. Delivering high-quality images, this portable and adaptable camera sets up quickly and can be connected directly to the latest Epson projectors.

See in great detail
Share high-quality visuals including detailed diagrams and textbook pages with a Full HD 1080p output and 8x digital zoom. You can even adjust the height and rotate the camera 90º to accommodate 3D objects.

Effortless to use
Minimise preparation time with this high-tech, compact and affordable portable solution, that makes it quick and easy to enlarge source material. In just seconds, you can connect directly to the latest Epson projectors using the two in one USB cable connection which provides power and transmits the video signal.

Highly portable, modern design
The Epson ELPDC07 visualiser is neat and compact, it features LED illumination, a built-in microphone and doesn’t need a separate power supply. It’s also light and easy to carry in the included carry case, with the arm folding neatly down into the base. Needing just 2.5W, you can be sure that its power consumption meets modern energy conservation requirements .

Specifications

Camera
Optical sensor size	25.4 / 2.7 mm (1 / 2.7")
Sensor type	CMOS
Effective sensor resolution	2 MP
Supported graphics resolutions	1920 x 1080 (HD 1080)
Maximum frame rate	30 fps
Image freeze	Yes
Light source	LED
Lens system
Auto focus	Yes
Digital zoom	8x
Shooting area (WxD)	297 x 420 mm
Ports & interfaces
Interface	USB 2.0
USB connector type	USB Type-B
Technical details
Image quality adjustment	Brightness
Illumination	Yes
Bundled software	Easy Interactive Tools, TWAIN-Treiber für Epson Dokumentenkamera (für Windows)
Product colour	White
Cable lock slot	Yes
Cable lock slot type	Kensington
Quantity per pack	1 pc(s)
Package width	195 mm
Package weight	1.73 kg
Package height	120 mm
Package depth	320 mm
Country of origin	Philippines
Display modes	Microscope
Power
Power supply type	USB
Power consumption (typical)	2.5 W
Power consumption (standby)	2.5 W
Weight & dimensions
Width	260 mm
Depth	388 mm
Height	76 mm
Weight	1 kg
Dimensions folded (WxDxH)	260 x 60 x 76 mm
Packaging data
Quantity per pack	1 pc(s)
Package width	195 mm
Package weight	1.73 kg
Package height	120 mm
Package depth	320 mm
Packaging content
Carrying case	Yes
Cables included	USB
Warranty card	Yes
