StarTech.com 8 Port 1U Rackmount USB KVM Switch with OSD

8 Port 1U Rackmount USB KVM Switch with OSD

Description

Control up to 8 VGA and USB computers from a single keyboard, mouse and monitor
The SV831DUSBU 8 Port 1U Rack Mount USB KVM Switch with OSD offers a dependable computer management tool that allows you to control up to 8 USB-connected computers from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hotkey commands or front panel push-buttons, and offers added configuration options and convenience through an On Screen Display (OSD).
A suitable addition to server room operations, the 8 port switch can be rack mounted into 1U of cabinet space, and can be cascaded with multiple KVM switches to deliver control of up to 64 computers from this single switch.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
- Cascade configuration supported for one spot control of up to 64 computers
- Rugged, rack mountable 1U metal chassis is ideal for any environment

Specifications

Ports & interfaces
Console USB ports quantity	2
Console ports	USB A, VGA (D-Sub)
Number of computers controlled	8
Keyboard port type	USB
Mouse port type	USB
Video port type	VGA
Audio connections	No
VGA (D-Sub) ports quantity	9
DC-in jack	Yes
Performance
Daisy chain	Yes
Plug and Play	Yes
Maximum resolution	1920 x 1440 pixels
Technical details
Product colour	Black
Rack mounting	Yes
Plug and Play	Yes
On Screen Display (OSD)	Yes
LED indicators	Yes
IP control	No
Audio support	No
Compliance certificates	RoHS
Design
Mean time between failures (MTBF)	150000 h
Product colour	Black
Rack mounting	Yes
LED indicators	Yes
Certification	CE, FCC, TAA, REACH
Rack capacity	1U
Housing material	Steel
Display
Built-in display	No
On Screen Display (OSD)	Yes
Power
Input current	0.8 A
Output current	1.5 A
Power plug type	Type M
Compatible power plug types	EU, UK, US
Output voltage	12 V
Input voltage	100 - 240 V
Video
Maximum resolution	1920 x 1440 pixels
Sustainability
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	540 mm
Depth	180 mm
Height	45 mm
Weight	2.9 kg
Package width	89 mm
Package depth	573 mm
Package height	268 mm
Package weight	3.3 kg
Packaging data
Package width	89 mm
Package depth	573 mm
Package height	268 mm
Package weight	3.3 kg
Packaging content
Rubber feet	Yes
Manual	Yes
AC adapter included	Yes
Certificates
Certification	CE, FCC, TAA, REACH
Other features
Connectivity technology	Wired
Power requirements	110 - 240 AC
Ports quantity	8
Dimensions (WxDxH)	540 x 180 x 45 mm
IP control	No
Audio support	No
Logistics data
Harmonized System (HS) code	85176200
