AOC AS110DX monitor mount / stand 81.3 cm (32") Desk Black

AS110DXGet your monitor in the optimum position easily with AS110's mechanical gas-spring arm with integrated USB Hub

Key Features

• USB 3.0 Hub
• Gas Spring
• VESA 75x75mm, 100x100mm
• Weight capacity range (each arm) 2 - 9 Kg

Reasons To Buy

Vesa Connection

Any monitor equipped with a VESA mounting grid (100x100 or 75x75) can easily be attached to the monitor arm. The VESA mounting system is a widely used solution that most monitors are equipped with. Four screws hold the monitor securely to the mount, by its centre of gravity.

Swivel & Tilt

Some monitor stands come with a limited tilt and swivel range. Using a monitor arm increases your monitor’s range of motion dramatically:  You can tilt the monitor in a wide range so it points upwards or downwards for the optimal viewing angle. The integrated swivel enables you to turn the display horizontally.

Mechanical Gas Spring System

Smooth motion in extension, retraction, or changing orientation. The precise mechanical gas-spring allows easy adjustment with just a firm hand move, and the monitor stays sturdily in its adjusted position. Easily adjust it anytime to get the most ergonomic position. Spring tension is adjustable for lighter/heavier monitors for easy movement and firmness.

Cable Management

Using the detachable covers on the monitor arm, simply push through your cables inside the pre-allocated routes in the monitor arm. After fitting both power and display cables inside, close the covers and experience a tidy desk with neatly organised connections. Cables are kept in place even when moving the display or turning it into portrait mode.

C-Lamp or Grommet Mount attachment

Your new AOC monitor arm is guaranteed to fit onto your desk. With either the grommet mount or the c-lamp method, you can easily fasten the mount to your tabletop. Your monitor will be firmly secured and ready for every gaming action.

USB Hub

Built in USB Hub provides an easy way to transmit data & charge your devices. The USB Hub is equipped with a USB 3.0 port supporting data transfer speed up to 5Gbps and a USB-C port supporting data transfer speed up to 5Gbps allowing you to transfer your favorite content & files in seconds. Use the integrated USB 3.0 male extension cords to connect your PC with the USB Hub, and boost your productivity with a clutter-free desk.

Description

Get your monitor in the optimum position easily with AS110's mechanical gas-spring arm with integrated USB Hub
AS110's sleek and sturdy, gas-spring controlled monitor arm enables wide range of ergonomics for your VESA (75 mm or 100 mm) supported monitor. Free up your desk with integrated cable management. Supports up to 32", 9 kg monitors and offers 320 mm height, 325 mm stretch, -45°/60° tilt, -90°/90° swivel and 360° pivot range for increased flexibility. Built in USB Hub provides an easy way to transmit data & charge your devices. The USB Hub is equipped with a USB 3.0 port supporting data transfer speed up to 5Gbps and a USB-C port supporting data transfer speed up to 5Gbps allowing you to transfer your favorite content & files in seconds. Use the integrated USB 3.0 male extension cords to connect your PC with the USB Hub, and boost your productivity with a clutter-free desk.

Specifications

Mounting
Maximum weight capacity (per display)	9 kg
Desk thickness (min)	1.5 cm
Desk thickness (max)	8 cm
Minimum screen size	33 cm (13")
Panel mounting interface	100 x 100,75 x 75 mm
Number of displays supported	1
Mounting type	Desk
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Mounting	Clamp/Bolt-through
Maximum weight capacity	9 kg
Maximum screen size	81.3 cm (32")
Clamp mount desk thickness (max)	8 cm
Grommet mount desk thickness (max)	8 cm
Mounting hole range	7 - 87 mm
Ergonomics
Cable management	Yes
Depth adjustment range	0 - 460 mm
Height adjustment	Yes
Height adjustment range	320 - 440 mm
Pivot angle	0 - 360°
Swivel angle range	-90 - 90°
Tilt angle range	-45 - 60°
Height adjustment type	Gas spring
Rotating	Yes
Tilt adjustment	Yes
Swivelling	Yes
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Design
Product colour	Black
Housing material	Aluminium
Ports & interfaces
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Technical details
Mounting type	Desk
Product colour	Black
Cable management	Yes
Warranty period	5 year(s)
Weight & dimensions
Weight	2.65 kg
Package width	280 mm
Package depth	410 mm
Package height	120 mm
Package weight	2.9 kg
Packaging data
Package width	280 mm
Package depth	410 mm
Package height	120 mm
Package weight	2.9 kg
Clamp included	Yes
Manual	Yes
Packaging content
Clamp included	Yes
Manual	Yes
Packaging content	User Manual, Monitor Arm, Clamp mount, Grommet mount, Installation materials
Mounting kit	Yes
Other features
Height (max)	58 cm
Warranty period	5 year(s)
Mounting type	Desk
Mounting	Clamp/Bolt-through
