Neomounts DS70-256BL1 Gaming monitor arm 24-57" - gas spring - Topfix - 180°-stop

Neomounts ACE DS70-256BL1 Gaming single monitor arm - 24-57" - 2-30 kg (curved 24 kg) - precision tilt - gas spring - 180°-stop - Topfix - Easy Install-model - black

Description

The Neomounts DS70-256BL1 ACE delivers exceptional performance and ergonomic comfort for gamers that want to take their setup to the highest level. Supporting screen sizes up to an impressive 57", including extra-wide models like the Samsung Odyssey G9, this arm is built to handle the most ambitious set-ups. With a heavy-duty weight capacity ranging from 2 to 30 kg (and up to 24 kg for curved monitors), it ensures maximum stability even during intense gaming sessions.

Thanks to its broad VESA compatibility from 75x75 to 200x200, the ACE offers seamless integration with a wide range of monitors. The inclusion of precision tilt functionality allows for finely tuned angle adjustments, reducing screen glare and enhancing viewing comfort no matter your setup. Combined with gas spring height adjustment and depth adjustment, positioning your screen in the ideal position becomes smooth and effortless, supporting better posture and sustained focus during marathon sessions.

For added practicality, the DS70-256BL1 monitor arm includes a smart 180° stop mechanism to prevent contact with nearby walls, ideal for space-constrained installations. The Quick-release VESA system ensures easy monitor mounting, while the included topfix clamp and grommet offer fast and secure installation.

Whether you're engaged in high-speed action, managing tactical operations, or streaming for hours, the full motion DS70-256BL1 ACE monitor arm empowers you with precision control, robust support, and optimum comfort so you can stay locked in and ahead of the competition.

Specifications

Mounting
Maximum weight capacity (per display)	30 kg
Desk thickness (min)	1.2 cm
Desk thickness (max)	4.5 cm
Minimum screen size	61 cm (24")
Panel mounting interface	100 x 200,100 x 100,200 x 100,200 x 200,75 x 75
Number of displays supported	1
Mounting type	Desk
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	200 x 200 mm
Mounting	Clamp/Grommet
Distance to the wall (min)	12.3 cm
Distance to the wall (max)	61.9 cm
Maximum weight capacity	30 kg
Maximum screen size	144.8 cm (57")
Maximum weight capacity (per curved/ultra-wide display)	24 kg
Ergonomics
Cable management	Yes
Adjustable depth	Yes
Depth adjustment range	90 - 586 mm
Height adjustment	Yes
Height adjustment range	310 - 570 mm
Swivel angle range	-90 - 90°
Tilt angle range	-45 - 70°
Angle of rotation	180°
Height adjustment type	Gas spring
Rotating	Yes
Swivelling	Yes
Width adjustment	99.2 cm
Design
Product colour	Black
Housing material	Aluminium
Technical details
Mounting type	Desk
Minimum weight	2 kg
Distance to the wall (min)	12.3 cm
Distance to the wall (max)	61.9 cm
Product colour	Black
Width adjustment range	0 - 992 mm
Cable management	Yes
Warranty period	5 year(s)
Weight & dimensions
Width	130 mm
Depth	123 mm
Height	675 mm
Weight	4.7 kg
Package width	155 mm
Package depth	143 mm
Package height	423 mm
Package weight	5.2 kg
Packaging data
Package width	155 mm
Package depth	143 mm
Package height	423 mm
Package weight	5.2 kg
Other features
Minimum weight	2 kg
Width adjustment range	0 - 992 mm
Warranty period	5 year(s)
Mounting type	Desk
Mounting	Clamp/Grommet
Country of origin	China
Logistics data
Master (outer) case width	356 mm
Master (outer) case length	290 mm
Master (outer) case height	510 mm
Master (outer) case gross weight	17.6 kg
Products per master (outer) case	4 pc(s)
Country of origin	China
Products per pallet (EU)	100 pc(s)
Master (outer) case net weight	14.2 kg
Harmonized System (HS) code	7616991099
