Vision 1195054500008 2.54 m (100") Floor Black

Height-Adjustable Display Floor Stand, Wall Fixing, 80 kg, 55-100″, Steel, black

Key Features

• Floor stand for displays up to 80 kg
• Fits displays with VESA sizes up to 800 x 600 mm
• For 55-100″ Displays
• (subject to VESA pattern and weight limit)
• Height adjustable by hand crank
• Wall and Floor Fixing

Description

Vision's F26W fixes a display against a wall and safely transfers the load to the floor. The height-adjusting hand crank features a mechanism that is easy to operate and reliable. Like all Vision products, it includes all necessary components and comes with an unbeatable lifetime warranty.

These attractive floor stands are ideal for meeting room facilities, schools, or any setting where large format displays are used.

SWL 80 kg (176 lbs)
The sturdy steel frame can support displays that weigh up to 80 kilograms.

55-100″ Displays
The suitability of a stand is also determined by the weight of the display and the dimensions of the mounting points. Displays that weigh under 80 kg and have a VESA pattern up to 800 x 600 mm are compatible with this stand.

Adjustable Height
Turn the crank handle located at the side of the column to adjust the display height by 400 mm (16 inches).

Tilt
The VESA mount is adjustable and can be tilted downwards to prevent reflections from overhead lighting.

Mini PC Mount
VESA100 mounting holes and M4 stand-offs are provided, allowing for attachment of a mini-PC, such as a Dell Optiplex or Intel NUC, to the VESA mount behind the display.

Cable Management
Vision considers every detail! Included are stick-on cable clips that allow for discreet cable routing up the column.

Specifications

Mounting
Maximum weight capacity (per display)	80 kg
Minimum screen size	139.7 cm (55")
Panel mounting interface	200 x 200,200 x 400,300 x 300,300 x 400,400 x 200,400 x 400,400 x 300,400 x 600,500 x 400,600 x 400,600 x 600,800 x 400,800 x 600
Number of displays supported	1
Mounting type	Floor
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	800 x 600 mm
Maximum weight capacity	80 kg
Maximum screen size	2.54 m (100")
Ergonomics
Cable management	Yes
Height adjustment	Yes
Height adjustment range	1439 - 1839 mm
Tilt angle range	0 - 3°
Height adjustment type	Manual
Tilt adjustment	Yes
Design
Product colour	Black
Housing material	Steel
Technical details
Mounting type	Floor
Product colour	Black
Cable management	Yes
Compliance certificates	RoHS, REACH
Weight & dimensions
Width	1200 mm
Depth	650 mm
Height	2170 mm
Weight	28.3 kg
Package width	520 mm
Package depth	1315 mm
Package height	260 mm
Package weight	36.3 kg
Packaging data
Package width	520 mm
Package depth	1315 mm
Package height	260 mm
Package weight	36.3 kg
Quantity per pack	1 pc(s)
Other features
Compliance certificates	RoHS, REACH
Mounting type	Floor
Country of origin	China
Logistics data
Country of origin	China
