Cisco

Cisco Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=)

SKU AIR-ANT2524DW-R=
£40.73
£27.84
£40.73
£27.84
Excluding taxes
Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 2 dBi (2.4 GHz)/4 dBi (5 GHz), White Dipole (1 Port), RP-TNC Connector, 1-Year Limited Hardware Warranty (AIR-ANT2524DW-R=)

Key Features

  • OMNIDIRECTIONAL WI-FI ANTENNA: 2 dBi (2.4 GHz)/4 dBi (5 GHz); white dipole (1 port); for use with Aironet 1830, 1850, 2800 and 3800 Series and Cisco Catalyst 9115AX, 9120AX and 9130AX Series access points
  • CONNECTION AND MOUNT: RP-TNC connector
  • 360-DEGREE RADIATION PATTERN: Intended for deployment when coverage in all directions from the antenna is required
  • PERFORMANCE: Designed for improved coverage
  • PEACE OF MIND: 1-year limited hardware warranty

Description

The Cisco Aironet AIR-ANT2524DW-R= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.

Specifications

Performance
Antenna gain level (max) 4 dBi
Frequency band 2.4/5 GHz
Impedance 50 Ω
Horizontal beam width (5 GHz) 39°
Horizontal beam width (2.4 GHz) 63°
Antenna gain (5 GHz) 4 dBi
Antenna gain (2.4 GHz) 2 dBi
Features
Country of origin China
Connector gender Male
Antenna gain level (max) 4 dBi
Frequency band 2.4/5 GHz
Antenna type Omni-directional antenna
Voltage Standing Wave Ratio (VSWR) 2:1
Purpose Indoor
Impedance 50 Ω
Horizontal beam width (5 GHz) 39°
Horizontal beam width (2.4 GHz) 63°
Product colour Grey
Antenna gain (5 GHz) 4 dBi
Antenna gain (2.4 GHz) 2 dBi
Antenna connector type RP-TNC
Technical details
Antenna gain level (max) 4 dBi
Frequency band 2.4/5 GHz
Antenna type Omni-directional antenna
Voltage Standing Wave Ratio (VSWR) 2:1
Purpose Indoor
Impedance 50 Ω
Horizontal beam width (5 GHz) 39°
Horizontal beam width (2.4 GHz) 63°
Frequency range 2.4 - 2.5GHz, 5.15 - 5.85GHz
Antenna gain (5 GHz) 4 dBi
Antenna gain (2.4 GHz) 2 dBi
Antenna connector type RP-TNC
Harmonized System (HS) code 85177100
Colour
Product colour Grey
Operational conditions
Operating temperature (T-T) -20 - 60 °C
Storage temperature (T-T) -40 - 85 °C
Weight & dimensions
Package width 152.4 mm
Package depth 184.2 mm
Package height 49.3 mm
Package weight 136.05 g
Weight 38.5 g
Width 21 mm
Depth 168.5 mm
Packaging content
Quantity per pack 1 pc(s)
Packaging content AIR-ANT2524DW-R Antenna
Logistics data
Quantity per pack 1 pc(s)
Harmonized System (HS) code 85177100
Other features
Frequency range 2.4 - 2.5GHz, 5.15 - 5.85GHz
