Intel Killer Wi-Fi 7 BE1750 i Internal WLAN / Bluetooth 5800 Mbit/s

Intel® Killer Wi-Fi 7 BE1750 i, 2230, 2x2 BE+BT, No vPro

Description

The Intel® Wi-Fi 7 BE201, a CRF (Companion RF) adapter, is designed to support the upcoming IEEE 802.11be standard – Wi-Fi 7 technology and the Wi-Fi Alliance Wi-Fi 7 certification. This Wi-Fi/ Bluetooth® module supports dual-stream Wi-Fi in the 2.4GHz, 5GHz and 6GHz bands as well as Bluetooth® 5.4. These new features maximize the benefits of Wi-Fi 7, including up to 5 Gigabit speed, ultra-low latencies, and enhanced reliability across new radio frequencies exclusive to Wi-Fi 7 devices, and deliver a significant improvement in user experience in dense deployments, as well as extended operating range for Bluetooth® connected devices, and support for Bluetooth® LE audio. Combined with Intel® Core™ processors and exceptional Intel® wireless innovations, the Intel® Wi-Fi 7 BE201 module can dramatically improve your connected experience at home, work, or on the go.

Specifications

Ports & interfaces
Internal	Yes
Interface	WLAN / Bluetooth
Host interface	M.2
Connectivity technology	Wireless
Bandwidth
Maximum data transfer rate	5800 Mbit/s
Wireless LAN features
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi	Yes
Antenna
Antenna type	2x2
Network
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi	Yes
Security algorithms	128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Bluetooth version	5.4
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11b, IEEE 802.11be, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Maximum data transfer rate	5800 Mbit/s
Bluetooth	Yes
Bluetooth Low Energy (BLE)	Yes
Design
Internal	Yes
Form factor	M.2 2230
Antenna type	2x2
Component for	Laptop
Software
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
System requirements
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90%
Weight & dimensions
Width	22 mm
Depth	30 mm
Height	2.42 mm
Weight	3.06 g
Security
Security algorithms	128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Performance
Ethernet adapter ARK ID	230083
Security algorithms	128-bit AES, 256-bit AES, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP, WPA2, WPA3-Enterprise, WPA3-Personal
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Technical details
Export Control Classification Number (ECCN)	5A991.B
Status	Launched
Launch date	Q2'24
Other features
Bluetooth version	5.4
Form factor	M.2 2230
Bluetooth	Yes
Ethernet adapter ARK ID	230083
Bluetooth Low Energy (BLE)	Yes
Status	Launched
Launch date	Q2'24
Export Control Classification Number (ECCN)	5A991.B
Antenna type	2x2
