TP-LINK

TP-Link TL-SG1210MP network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

SKU TL-SG1210MP
£123.26
£78.22
£123.26
£78.22
Excluding taxes
TP-Link TL-SG1210MP, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)

Description

TP-Link TL-SG1210MP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 4000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Power over Ethernet (PoE)

Specifications

Management features
Switch type Unmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 9
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity 0
Installed SFP+ modules quantity 0
Combo SFP ports quantity 1
Copper ethernet cabling technology 10BASE-T, 100BASE-TX
Network
Cable types supported Cat3, Cat4, Cat5, Cat5e
MAC address auto-learning supported Yes
MAC address auto-aging supported Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX
Networking standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Flow control support Yes
Auto MDI/MDI-X Yes
10G support No
Auto-negotiation Yes
Data transmission
Packet buffer memory 14.88 MB
MAC address table 4000 entries
Switching capacity 20 Gbit/s
Store-and-forward Yes
Design
Product colour Black
LED indicators Yes
Rack mounting No
Certification CE, FCC
Performance
Fanless Yes
Packet buffer memory 14.88 MB
Auto-negotiation Yes
Harmonized System (HS) code 85176990
Power
Power consumption (max) 141.4 W
Input voltage 53.5 V
Input current 2.43 A
Power source DC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet plus (PoE+) ports quantity 8
Total Power over Ethernet (PoE) budget 123 W
Power over Ethernet (PoE) Yes
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90%
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Heat dissipation 482.17 BTU/h
Weight & dimensions
Width 209 mm
Depth 126 mm
Height 26 mm
Packaging content
Quick start guide Yes
Packaging data
Package width 240 mm
Package depth 315 mm
Package height 70 mm
Package weight 1.41 kg
Quick start guide Yes
Technical details
Product colour Black
Rack mounting No
Memory
Packet buffer memory 14.88 MB
Certificates
Certification CE, FCC
Indication
LED indicators Yes
Other features
Input voltage 53.5 V
Logistics data
Harmonized System (HS) code 85176990
