Cisco

Cisco 25GBASE-SR SFP Module for 25-Gigabit Ethernet Deployments, SFP28 Form Factor, 5-Year Standard Warranty (SFP-25G-SR-S=)

SKU SFP-25G-SR-S=
£902.25
£375.97
£902.25
£375.97
Excluding taxes
25GBASE-SR SFP Module for 25-Gigabit Ethernet Deployments, SFP28 Form Factor, 5-Year Standard Warranty (SFP-25G-SR-S=)

Key Features

  • LINK LENGTH: Supports a link length of 70/100 m on OM3/4 multimode fibre (this module requires RS-FEC on the host ports)
  • COMPATIBILITY: Interoperable with other IEEE-compliant 25G interfaces where applicable
  • RELIABILITY: Certified and tested on Cisco SFP28 ports for superior performance, quality and reliability
  • PERFORMANCE: SFP receiver/transceiver module is high-speed connectivity compliant to IEEE 802.3by and IEEE 802.3cc
  • PEACE OF MIND: 5-year standard replacement warranty

Description

The Cisco 25GBASE-SR-S SFP Module delivers a variety of high-density and low-power 25-Gigabit Ethernet connectivity options for data centre and high-performance computing network applications. Based on an SFP28 form factor, this SFP module is interoperable with other IEEE-compliant 25G interfaces where applicable and is high-speed connectivity compliant to IEEE 802.3by and IEEE 802.3cc.

Specifications

Network
SFP transceiver type Fiber optic
Maximum data transfer rate 25000 Mbit/s
Interface type SFP28
Technical details
Package width 143 mm
Package height 44.5 mm
Maximum transfer distance 100 m
Wavelength 850 nm
Tx power (min) -8.4 dBmW
Tx power (max) 2.4 dBmW
Rx power (min) -10.3 dBmW
Rx power (max) 2.4 dBmW
Performance
Country of origin China
SFP transceiver type Fiber optic
Maximum transfer distance 100 m
Wavelength 850 nm
Tx power (min) -8.4 dBmW
Tx power (max) 2.4 dBmW
Rx power (min) -10.3 dBmW
Rx power (max) 2.4 dBmW
Maximum data transfer rate 25000 Mbit/s
Interface type SFP28
Multi-mode fiber (MMF) supported Yes
Features
Country of origin China
Power
Power consumption (typical) 1.2 W
Packaging data
Package depth 158.8 mm
Package width 143 mm
Package height 44.5 mm
Package weight 90.7 g
Weight & dimensions
Package depth 158.8 mm
Package width 143 mm
Package height 44.5 mm
Package weight 90.7 g
Logistics data
Quantity per pack 1 pc(s)
