StarTech.com MSA Compliant SFP Transceiver Module - 1000BASE-TX~MSA Uncoded SFP Module - 1000BASE-TX - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m

StarTech.com MSA Uncoded Compatible SFP Module - 1000BASE-TX - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m -(SFP1000TXST)

Key Features

• 100% MSA UNCODED SFP TRANSCEIVER: Designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver reliable 1GbE connectivity
• TECHNICAL SPECS: 1000BASE-TX / 1Gbps / Copper / RJ-45 Connector / / Distances up to 100m (328ft)
• TESTED FOR COMPATIBILITY: Hot-swappable in MSA Compliant routers and switches
• Uses a cost-effective cabling alternative to fiber-optic set ups
• WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
• THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance

Description

1000 Mbps (1 Gbps) | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty

The SFP1000TXST is an MSA compliant copper SFP transceiver that’s designed, programmed and tested to work with 1000BASE-TX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 100 m (328 ft) and delivers dependable 1 GbE connectivity over copper cabling.

Technical Specifications:

• Maximum Data Transfer Rate: 1000 Mbps
• Type: Copper
• Connection Type: RJ45 Connector
• Maximum Transfer Distance: 100 m (328 ft)
• Power Consumption: Less than 1.3 Watt
• DDM: No

This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Specifications

Performance
SFP transceiver type	Copper
Ethernet LAN	Yes
Digital Diagnostics Monitoring (DDM)	No
Networking standards	IEEE 802.3z
Ethernet LAN (RJ-45) ports	1
Maximum transfer distance	100 m
Duplex system	Full
Maximum data transfer rate	1000 Mbit/s
Interface type	SFP
SFP transceiver standard	TX
Country of origin	China
Product colour	Silver
Housing material	Aluminium
Hot-Plug support	Yes
Harmonized System (HS) code	85369010
Features
Product colour	Silver
Housing material	Aluminium
Hot-Plug support	Yes
Country of origin	China
Certification	CE, FCC, UR
Power
Power consumption (typical)	1.3 W
Certificates
Certification	CE, FCC, UR
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%
Network
SFP transceiver type	Copper
Networking standards	IEEE 802.3z
Ethernet LAN (RJ-45) ports	1
Maximum data transfer rate	1000 Mbit/s
Interface type	SFP
Weight & dimensions
Width	13.9 mm
Depth	58.4 mm
Height	12.6 mm
Weight	25 g
Package depth	120 mm
Package width	90 mm
Package height	30 mm
Package weight	52 g
Packaging content
Quantity per pack	1 pc(s)
Technical details
Package width	90 mm
Package height	30 mm
Hot-Plug support	Yes
Maximum transfer distance	100 m
Duplex system	Full
Ethernet LAN	Yes
Compliance certificates	RoHS
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Packaging data
Package depth	120 mm
Package width	90 mm
Package height	30 mm
Package weight	52 g
Logistics data
Quantity per pack	1 pc(s)
Country of origin	China
Master (outer) case width	310 mm
Master (outer) case length	400 mm
Master (outer) case height	320 mm
Products per master (outer) case	70 pc(s)
Harmonized System (HS) code	85369010
