StarTech.com MSA Uncoded SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber (MMF) Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM

StarTech.com MSA Uncoded Compatible SFP Module - 1000BASE-SX - 1GbE Multi Mode Fiber (MMF) Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM (SFPSXMM)

Key Features

• 100% MSA UNCODED SFP TRANSCEIVER: Designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver reliable 1GbE connectivity
• TECHNICAL SPECS: 1000BASE-SX / 1Gbps / Multi Mode (MMF) / LC Connector / 850nm / Digital Diagnostic Monitoring (DDM) / Distances up to 550m (1804ft)
• TESTED FOR COMPATIBILITY: Hot-swappable in MSA Compliant routers and switches
• WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
• THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance

Description

1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | TAA | Lifetime Warranty

The SFPSXMM is a TAA compliant MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 1000BASE-SX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 550 m (1804 ft) and delivers dependable 10 GbE connectivity over fiber cabling.

Technical Specifications:

• Wavelength: 850 nm
• Maximum Data Transfer Rate: 1.25 Gbps
• Type: Multi Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 550 m (1804 ft)
• MTBF: 78,286 hours
• Power Consumption: Less than 1 Watt
• DDM: No

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Specifications

Performance
SFP transceiver type	Fiber optic
Digital Diagnostics Monitoring (DDM)	No
Fiber optic connector	LC
Networking standards	IEEE 802.3z
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Multi-mode fiber (MMF) supported	Yes
SFP transceiver standard	SX
Fiber ethernet cabling technology	1000BASE
Product colour	Silver
Hot-swap	Yes
Mean time between failures (MTBF)	78286 h
Brand compatibility	MSA Compliant
Harmonized System (HS) code	85369010
Features
Product colour	Silver
Hot-swap	Yes
Mean time between failures (MTBF)	78286 h
Brand compatibility	MSA Compliant
Certification	CE, FCC, UL, TAA, REACH
Power
Power consumption (typical)	1 W
Certificates
Certification	CE, FCC, UL, TAA, REACH
Compliance certificates	RoHS
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95%
Network
SFP transceiver type	Fiber optic
Fiber optic connector	LC
Networking standards	IEEE 802.3z
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Weight & dimensions
Width	13 mm
Depth	55 mm
Height	9 mm
Weight	18 g
Package depth	115 mm
Package width	25 mm
Package height	65 mm
Package weight	40 g
Packaging content
Quantity per pack	1 pc(s)
Technical details
Package width	25 mm
Package height	65 mm
Hot-swap	Yes
Maximum transfer distance	550 m
Wavelength	850 nm
Duplex system	Full
Dimensions (WxDxH)	13 x 55 x 9 mm
Compliance certificates	RoHS
Packaging data
Package depth	115 mm
Package width	25 mm
Package height	65 mm
Package weight	40 g
Logistics data
Quantity per pack	1 pc(s)
Master (outer) case width	220 mm
Master (outer) case length	560 mm
Master (outer) case height	210 mm
Products per master (outer) case	100 pc(s)
Harmonized System (HS) code	85369010
Other features
Dimensions (WxDxH)	13 x 55 x 9 mm
