TP-LINK

TP-Link SM6110-LR network transceiver module Fiber optic 25780 Mbit/s SFP+ 1310 nm

SKU SM6110-LR
£51.45
£51.45
Excluding taxes
Omada 25GBase-LR SFP28 LC Transceiver

Key Features

  • Single-mode SFP+/SFP28 LC Transceiver
  • Hot-Pluggable with maximum flexibility
  • Supports Digital Diagnostic Monitoring (DDM)
  • Low Power Consumption no more than 1.2 W
  • Compatible with 10G/25G Small Form Pluggable Multi-Source Agreement (SFP+/SFP28 MSA)
  • Compatible with switches with 25G ports like SX6632YF; and 10G ports like SG3428X and SG3452X

Description

The SM6110-LR is designed to extend transfer distances based on 10G/25G Ethernet connectivity. It is a 10G/25GBASE-LR high performance 1310 nm single-mode SFP+/SFP28 transceiver. It supports full duplex, 10G/25G Ethernet connections up to 10 km with 9/125µm fiber cables respectively.

Specifications

Performance
SFP transceiver type Fiber optic
Maximum transfer distance 10000 m
Wavelength 1310 nm
Fiber cable diameters supported (core/cladding) 9/125 µm
Maximum data transfer rate 25780 Mbit/s
Interface type SFP+
Product colour Grey
Hot-Plug support Yes
Hot-swap Yes
Features
Product colour Grey
Hot-Plug support Yes
Hot-swap Yes
Power
Input voltage 3.3 V
Operational conditions
Storage temperature (T-T) -40 - 85 °C
Storage relative humidity (H-H) 5 - 90%
Minimum operating temperature 0 °C
Maximum operating temperature 70 °C
Network
SFP transceiver type Fiber optic
Maximum data transfer rate 25780 Mbit/s
Interface type SFP+
Weight & dimensions
Width 57 mm
Depth 14 mm
Height 12 mm
Packaging content
Quantity per pack 1 pc(s)
Technical details
Hot-Plug support Yes
Hot-swap Yes
Maximum transfer distance 10000 m
Wavelength 1310 nm
Fiber cable diameters supported (core/cladding) 9/125 µm
Logistics data
Quantity per pack 1 pc(s)
