Lenovo ThinkSystem SR650 V4 server Rack (2U) Intel Xeon 6 6515P 2.3 GHz 32 GB DDR5-SDRAM 1300 W

Intel Xeon 6 6515P (72MB Cache, 2.3GHz), 32GB DDR5-SDRAM, LAN, 940-8i 4GB, 1300W

Key Features

• Intel Xeon 6 6515P (72MB Cache, 2.3GHz)
• 32GB DDR5-SDRAM (1 x 32)

Description

The Lenovo ThinkSystem SR650 V4 is an ideal 2-socket 2U rack server for customers that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. With two Intel Xeon 6700-series or 6500-series processors, the SR650 V4 is designed for high density and scale-out workloads in various customer segments.

This product guide provides essential pre-sales information to understand the ThinkSystem SR650 V4 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR650 V4 and consider its use in IT solutions.

Specifications

Processor
Processor threads	32
Processor cache	72 MB
Processor frequency	2.3 GHz
Processor boost frequency	3.8 GHz
Number of processors installed	1
Processor model	6515P
Processor cores	16
Processor manufacturer	Intel
Processor family	Intel Xeon 6
Memory
Internal memory	32 GB
Memory layout (slots x size)	1 x 32 GB
Memory slots	32x DIMM
Maximum internal memory	8 TB
Internal memory type	DDR5-SDRAM
ECC	Yes
Storage
Supported RAID controllers	940-8i 4GB
Supported storage drive interfaces	SAS
Hot-swap	Yes
Supported HDD sizes	2.5"
RAID support	Yes
Optical drive type	No
Number of HDDs supported	8
Internal drive bays	8
Graphics
Maximum graphics card memory	16 MB
On-board graphics card	Yes
Network
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Cabling technology	10/100/1000Base-T(X)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
VGA (D-Sub) ports quantity	1
Ethernet LAN (RJ-45) ports	1
Optical drive
Optical drive type	No
Design
Rack mounting	Yes
Optical drive type	No
Chassis type	Rack (2U)
Product colour	Black, Steel
Cooling type	Active
Performance
Compatible operating systems	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server
Performance management	XClarity Controller Platinum
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Software
Compatible operating systems	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi, Ubuntu Server
Power
Number of main power supplies	2
Redundant power supply (RPS) support	Yes
Power supply	1300 W
Management features
Performance management	XClarity Controller Platinum
Technical details
Trusted Platform Module (TPM) version	2.0
Trusted Platform Module (TPM)	Yes
Supported HDD sizes	2.5"
Rack mounting	Yes
Ethernet interface type	Gigabit Ethernet
Chassis type	Rack (2U)
Supported storage drives form factor (internal)	2.5"
Compliance certificates	CCC, CE, CECP, Federal Communications Commission (FCC), RoHS, UKCA, UL
Weight & dimensions
Width	445 mm
Height	43 mm
Depth	796 mm
