Lindy 3m USB 3.2 Gen 2 C/C Active Cable

3m USB 3.2 Gen 2 C/C Active Cable

Key Features

• 3 metre USB 3.2 Gen 2 Active Cable for data and video extension
• Data transfer rates up to 10Gbps
• Supports DisplayPort 1.4 Alternate Mode
• Supports video resolutions up to UHD 8K 7680x4320@60Hz including 4K 4096x2160@120Hz
• 2 year warranty

Description

USB active cables allow users to extend the connection distance between two USB devices. These cables feature integrated active electronics to boost the signal for high speed data transfer.

The Lindy USB 3.2 Gen 2 Active Cable uses built-in active electronics to extend the cable length of a USB device by an additional 3m whilst continuing to support fast and efficient data transfer rates of up to 10Gbps as well as Displayport 1.4 Alternate Mode. It combines data, video and USB Power Delivery into one cable which makes it a great solution for use in modern meeting rooms and classrooms when connecting LFDs and touchpanels.

When sending DP 1.4 signals, only USB 2.0 up to 480Mbps can be supported. USB 3.2 Gen 2 with data rates up to 10Gbps can be achieved when sending DP 1.2 signals with resolutions up to 4K 60Hz. The cable also supports Power Delivery up to 60W (20V / 3A). Compatible with USB 3.2 Type C and Thunderbolt 3/4 equipped computers, this is a perfect extension tool for the latest laptops, Macbooks and Type C computers. With plug and play functionality, this extension cable can be installed quickly and with minimum fuss.

Information about USB 3.0, 3.1 and 3.2

USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.

USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.

USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.

Specifications

Features
Connector 1 form factor	Straight
Connector 2 form factor	Straight
USB version	USB 3.2 Gen 2 (3.1 Gen 2)
Connector 1	USB C
Connector 2	USB C
Cable length	3 m
Connector contacts plating	Nickel
Maximum data transfer rate	10000 Mbit/s
Product colour	Black
Certification	CE, FCC, RoHS & REACH
Connector 1 gender	Male
Connector 2 gender	Male
Conductor material	Tinned copper
USB Power Delivery (USB PD)	Yes
Cable jacket material	Polyvinyl chloride (PVC)
USB Power Delivery up to	60 W
Maximum data transfer rate	10 Gbit/s
Cable diameter	5.3 mm
Weight	130 g
Quantity per pack	1 pc(s)
Weight & dimensions
Cable diameter	5.3 mm
Cable length	3 m
Weight	130 g
Package width	236 mm
Package height	255 mm
Package weight	200 g
Package type	Polybag
Packaging data
Package width	236 mm
Package height	255 mm
Package weight	200 g
Package type	Polybag
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)
Ports & interfaces
USB version	USB 3.2 Gen 2 (3.1 Gen 2)
Connector 1	USB C
Connector 2	USB C
Connector contacts plating	Nickel
Data transmission
Maximum data transfer rate	10000 Mbit/s
Technical details
Product colour	Black
Harmonized System (HS) code	84733080
Certificates
Certification	CE, FCC, RoHS & REACH
Other features
Package type	Polybag
Product colour	Black
Logistics data
Harmonized System (HS) code	84733080
