StarTech.com 1ft (30cm) HDMI to DisplayPort Adapter Cable, 8K 60Hz, Active HDMI 2.1 to DP 1.4 Video Converter, USB Bus Powered with Included Cable

StarTech.com 1ft/30cm HDMI to DisplayPort Adapter Cable, 8K 60Hz, Active HDMI 2.1 to DP 1.4 Video Converter, USB Bus Powered

Key Features

• HDMI TO DISPLAYPORT CONVERSION: Active Adapter Cable converts an HDMI 2.1 source to a DisplayPort 1.4 output for connecting a DisplayPort monitor; Utilizes the integrated or dedicated GPU, enabling high-performance video with minimal CPU usage
• 8K 60HZ RESOLUTION: Supports up to 7680 x 4320 at 60Hz, ideal for high-resolution graphics and video; Supports lower resolutions/refresh rates such as 4K 120Hz, 4K 60Hz, and 1080p; DSC support is required for maximum video performance capability
• NO DRIVERS OR SOFTWARE: Universal Video Converter is compatible with any OS (i.e., Windows, macOS, ChromeOS, Linux); Works with HDMI-enabled laptops, tablets, MacBooks, and Chromebooks from all hardware platforms (i.e. Intel, Nvidia, AMD, Apple Silicon)
• REDUCED PORT STRAIN: HDMI to DP Adapter features a 1-foot (30cm) cable between the HDMI and DP connectors, reducing strain on both the ports and cables; Included 1.6ft (50cm) USB power cable connects to any available USB-A port or USB Wall Charger
• TECH SPECS: Unidirectional, HDMI source to DisplayPort display; HDMI 2.1 compliant supporting HDCP 1.4/2.2/2.3, DSC 1.2a, HDR (up to 10-bit RGB/YCbCr 4:4:4), CEC, ARC, and 2.1ch audio; USB powered with the included cable, power is required for operation

Description

Connect an HDMI-enabled source to a DisplayPort monitor with support for resolutions up to 8K at 60Hz

This HDMI 2.1 to DisplayPort 1.4 adapter connects an 8K 60Hz HDMI video source, such as a laptop or desktop, to a DisplayPort monitor.

8K 60Hz Resolution

This 1ft (30cm) HDMI to DisplayPort video converter supports resolutions up to 7680 x 4320 at 60Hz*. It supports HDR, HDCP 2.3, CEC, ARC, and 2-channel DisplayPort audio. Additionally, it supports lower resolutions such as 4K 120Hz, 4K 60Hz, and 1080p.

*DSC support on the host is required to achieve maximum video performance.

No Drivers or Software Required

This universal active adapter utilizes integrated or dedicated GPUs, enabling high-performance video with minimal CPU usage. It requires no drivers or software and works with any HDMI-enabled laptop, desktop, Ultrabook, MacBook, or Chromebook. It is compatible with any operating system, including Windows, macOS, Ubuntu, and ChromeOS.

Extended Cables

This HDMI to DP adapter features a 1ft (30cm) cable between the HDMI and DP connectors, reducing strain on ports and connectors. The adapter includes a 1.6-foot (50cm) USB power cable for connecting to a powered USB port anywhere on the laptop or to a USB wall charger. Power is required for the adapter to function.

The StarTech.com Advantage

Specifications

Features
Chipset	LT6711GX-U3
Colour depth	10 bit
HDMI version	2.1
DisplayPort version	1.4
Product colour	Black, Silver
Cable length	0.3 m
Connector 1	HDMI Type A (Standard)
Connector 2	DisplayPort
Connector 1 gender	Male
Connector 2 gender	Female
Maximum resolution	7680 x 4320 pixels
Supported graphics resolutions	800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1366 x 768, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1536 (QXGA), 2560 x 1440, 3072 x 1728, 3200 x 1800, 3840 x 2160, 5120 x 2880, 7680 x 4320
HDCP	Yes
Plug and Play	Yes
Windows operating systems supported	Yes
Mac operating systems supported	Yes
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Audio Return Channel (ARC)	Yes
Linux operating systems supported	Yes
Other operating systems supported	ChromeOS
Maximum refresh rate	120 Hz
HDCP version	1.4/2.2/2.3
High Dynamic Range (HDR) supported	Yes
Power source	USB
Colour sampling	4:4:4
Cable type	Round cable
Refresh rate at maximum resolution	60 Hz
Sustainability
Sustainability compliance	Yes
Technical details
Sustainability compliance	Yes
Compliance certificates	RoHS
Other features
Width	31 mm
Height	12 mm
Depth	372 mm
Weight & dimensions
Width	31 mm
Height	12 mm
Depth	372 mm
Weight	32 g
Package width	80 mm
Package depth	150 mm
Package height	20 mm
Package weight	51 g
Packaging data
Package width	80 mm
Package depth	150 mm
Package height	20 mm
Package weight	51 g
Quantity per pack	1 pc(s)
Packaging content
Quantity per pack	1 pc(s)
Logistics data
Master (outer) case width	331 mm
Master (outer) case length	473 mm
Master (outer) case height	440 mm
Products per master (outer) case	220 pc(s)
