Ubiquiti

Ubiquiti U7 Outdoor 4300 Mbit/s White Power over Ethernet (PoE)

SKU U7-OUTDOOR
£153.47
£153.47
Excluding taxes
WiFi 7, 4 spatial streams, 2.5 GbE RJ45 port, PoE+, 19W, IPX6, UV-stabilized polycarbonate, aluminum alloy, white

Key Features

  • WiFi 7
  • 4 spatial streams
  • 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
  • Software-adjustable antenna beamwidth for balanced coverage with the included omni antennas
  • 200+ connected devices
  • Powered using PoE+
  • 2.5 GbE uplink
  • Versatile wall and pole mounting
  • Weatherproof (outdoor exposed)

Description

All-weather WiFi 7 AP with 4 spatial streams, an integrated directional super antenna, and versatile mounting options.

Specifications

Data transmission
Ethernet LAN data rates 2500 Mbit/s
Maximum data transfer rate 4300 Mbit/s
Performance
2.4 GHz Yes
5 GHz Yes
Reset button Yes
Frequency band 2.4 - 5 GHz
VLAN support Yes
Rate limiting Yes
Quality of Service (QoS) support Yes
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Ethernet LAN data rates 2500 Mbit/s
Maximum data transfer rate 4300 Mbit/s
MIMO type Multi User MIMO
MIMO Yes
Wireless LAN features
Frequency band 2.4 - 5 GHz
Network
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Management features
VLAN support Yes
Rate limiting Yes
Quality of Service (QoS) support Yes
Features
6 GHz No
2.4 GHz Yes
5 GHz Yes
Frequency band 2.4 - 5 GHz
VLAN support Yes
Rate limiting Yes
Quality of Service (QoS) support Yes
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Ethernet LAN data rates 2500 Mbit/s
Maximum data transfer rate 4300 Mbit/s
MIMO type Multi User MIMO
MIMO Yes
Throughput data rate 4324 Mbit/s
Spatial streams 4
Security
Security algorithms PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Power
Power consumption (max) 19 W
Power over Ethernet (PoE) Yes
DC voltage range 44 - 57 V
Design
International Protection (IP) code IPX6
Housing material Aluminium, Polycarbonate (PC)
Placement Ceiling, Pole, Wall
Product colour White
Reset button Yes
LED indicators Yes
Recommended usage Outdoor
Antenna
Number of connectors 2
Antenna type External
Antennas quantity 2
Antenna gain level (max) 12.5 dBi
Antenna connector type RP-SMA
Antenna direction type Omni-directional
Antenna features Detachable antenna
Technical details
Reset button Yes
Sustainability compliance Yes
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
Certificates
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
Indication
LED indicators Yes
Weight & dimensions
Width 170 mm
Depth 54.5 mm
Weight 1.2 kg
Height 208 mm
Packaging data
Mounting kit Yes
Packaging content
Mounting kit Yes
Quantity per pack 1 pc(s)
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Operating temperature (T-T) -30 - 60 °C
Sustainability
Sustainability compliance Yes
Logistics data
Quantity per pack 1 pc(s)
