Cisco Catalyst 9115AXI-E Wireless Access Point, Wi-Fi 6, 4x4 MU-MIMO, Controller Managed, PoE, Internal antenna, (C9115AXI-E)

Catalyst 9115AXI-E Wireless Access Point, Wi-Fi 6, 4x4 MU-MIMO, Controller Managed, PoE, Internal antenna

Key Features

• POWERFUL Wi-Fi 6 PERFORMANCE: 4x4 Dual Radio, MU-MIMO Wi-Fi 6, up to 5.38 Gbps data rate, uplink/downlink OFDMA for latency reduction, MU-MIMO for maximising throughput, BBS colouring for increased density, TWT for device energy efficiency
• INTEGRATED BLE: Bluetooth Low Energy (BLE) 5.0 radio enables location-based use cases such as wayfinding and asset tracking
• ECOSYSTEM: End-point interoperability and optimised performance on Apple and Samsung devices
• EMBEDDED WIRELESS CONTROLLER: Controller functions embedded in the Access Point for easy deployment, network monitoring and troubleshooting. Support with WebGUI and mobile app (C9115AXI(E)-EWC models only)
• PEACE OF MIND: 90-day software and limited lifetime hardware warranty

Description

The Cisco Catalyst 9115 Access Points go beyond the Wi-Fi 6 (802.11ax) standard, providing radio-frequency excellence for high-density environments. These access points are resilient and intelligent while providing integrated security for mobile and IoT devices. Ideal for small to medium-size networks. Pairing with Cisco DNA, it further offers real-time analytics, quickly detect and contain security threats, and a network-wide consistency through automation and virtualisation.

Specifications

Data transmission
Ethernet LAN data rates	2500 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Country of origin	Mexico
Networking standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Internal memory	2048 MB
Flash memory	1024 MB
Network
Networking standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Memory
Internal memory	2048 MB
Flash memory	1024 MB
Features
2.4 GHz	Yes
5 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
Maximal-Ratio Combining (MRC)	Yes
Cyclic Shift Diversity (CSD)	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Internal memory	2048 MB
Flash memory	1024 MB
Ports & interfaces
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power plug type	Type C
Power over Ethernet (PoE)	Yes
Design
Placement	In-wall
Country of origin	Mexico
Product colour	Grey
LED indicators	Status
Antenna
Antenna type	Internal
Antenna gain level (max)	4 dBi
Technical details
Products per shipping (inner) case	1 pc(s)
Harmonized System (HS) code	85176990
Indication
LED indicators	Status
Software
Maximal-Ratio Combining (MRC)	Yes
Cyclic Shift Diversity (CSD)	Yes
Weight & dimensions
Width	203 mm
Depth	203 mm
Weight	900 g
Height	38 mm
Package width	230.1 mm
Package depth	249.2 mm
Package height	84.1 mm
Package weight	530.61 g
Packaging data
Package width	230.1 mm
Package depth	249.2 mm
Package height	84.1 mm
Package weight	530.61 g
Packaging content
Quantity per pack	1 pc(s)
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-30 - 70 °C
Operating altitude	0 - 3000 m
Logistics data
Country of origin	Mexico
Products per master (outer) case	1 pc(s)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
