Cisco Catalyst 9120AXE-E Wireless Access Point, Wi-Fi 6, 4x4 Dual 5GHz Radio, MU-MIMO, CleanAir with RF ASIC, PoE, External antenna, (C9120AXE-E)

Catalyst 9120AXE-E Wireless Access Point, Wi-Fi 6, 4x4 Dual 5GHz Radio, MU-MIMO, CleanAir with RF ASIC, PoE, External antenna, (C9120AXE-E)

Key Features

• POWERFUL Wi-Fi 6 PERFORMANCE: 4x4 Flexible Dual Radio with 5GHz and 2.4GHz or two 5GHz configuration, up to 5.38 Gbps data rate, uplink/downlink OFDMA, MU-MIMO, BBS colouring, TWT and Embedded IoT radios enabling BLE 5.0 and Zigbee
• CISCO CLEANAIR: Powered by Cisco RF ASIC, offer superior analytics and security
• ECOSYSTEM: End-point interoperability and optimised performance on Apple and Samsung devices
• EMBEDDED WIRELESS CONTROLLER: Controller functions embedded in the Access Point for easy deployment, network monitoring and troubleshooting. Support with WebGUI and mobile app (C9120AXI(E)-EWC models only)
• PEACE OF MIND: 90-day software and limited lifetime hardware warranty

Description

The Catalyst 9120 Access Points are designed for mission-critical deployments with dual 5-GHz and integrated IoT radio. With CleanAir technology powered by Cisco RF ASIC, the C9120 access point goes beyond the Wi-Fi 6 (802.11ax) standard, providing radio-frequency excellence for high-density environments. These access points are resilient and intelligent while providing integrated security for mobile and IoT devices. Pairing with Cisco DNA, it further offers real-time analytics, quickly detect and contain security threats, and a network-wide consistency through automation and virtualisation.

Specifications

Data transmission
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Maximum data transfer rate	5000 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Syslog	Yes
Country of origin	Mexico
On/off switch	Yes
Firmware upgradeable	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Channels quantity	29 channels
Maximum data transfer rate	5000 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Internal memory	2048 MB
Flash memory	1024 MB
Wireless LAN features
Channels quantity	29 channels
Network
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Memory
Internal memory	2048 MB
Flash memory	1024 MB
Features
2.4 GHz	Yes
5 GHz	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	100,1000,2500,5000 Mbit/s
Channels quantity	29 channels
Maximum data transfer rate	5000 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	2500 Mbit/s
Maximum data transfer rate (5 GHz)	5000 Mbit/s
Internal memory	2048 MB
Flash memory	1024 MB
Security
Security algorithms	AES, EAP, EAP-GTC, EAP-SIM, MSCHAPv2, TLS, TTLS, WPA, WPA2, WPA3
Management features
Syslog	Yes
Firmware upgradeable	Yes
Ports & interfaces
Internal RJ-45 ports quantity	1
WAN connection	Ethernet (RJ-45), Mobile network (SIM), Wi-Fi
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	1
Power
Power plug type	Type C
Power over Ethernet (PoE)	Yes
Design
Placement	Ceiling, Floor, Table
Country of origin	Mexico
On/off switch	Yes
Product colour	White
Antenna
Number of connectors	2
Antenna type	Internal & external
Antennas quantity	4
Antenna gain level (max)	6 dBi
Antenna connector type	RP-TNC
Antenna direction type	Omni-directional
Antenna features	Detachable antenna
Technical details
Firmware upgradeable	Yes
Products per shipping (inner) case	1 pc(s)
Harmonized System (HS) code	85176990
Weight & dimensions
Width	216 mm
Depth	216 mm
Weight	1.36 kg
Height	51 mm
Package width	244.6 mm
Package depth	263.7 mm
Package height	90.4 mm
Package weight	671.2 g
Packaging data
PoE adapter included	Yes
CD manual	Yes
Package width	244.6 mm
Package depth	263.7 mm
Package height	90.4 mm
Package weight	671.2 g
AC adapter included	Yes
Packaging content
PoE adapter included	Yes
AC adapter included	Yes
Quantity per pack	1 pc(s)
CD manual	Yes
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-39 - 70 °C
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4572 m
Logistics data
Country of origin	Mexico
Products per master (outer) case	1 pc(s)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
