Cisco Meraki MR78-HW wireless access point 54 Mbit/s White

2.4 GHz 802.11b/g/n/ax client access radio, 1x 10/100/1000 BASE-T Ethernet (RJ45), 5 GHz 802.11a/n/ac/ax client access radio

Key Features

• 2x2:2 MU-MIMO 802.11ax
• 1.5* Gbps dual-radio aggregate frame rate
• Enhanced transmit power and receive sensitivity
• Integrated enterprise security and guest access
• Application-aware traffic shaping
• Optimized for voice and video
• Self-configuring, plug-and-play deployment

Description

Entry Level Cloud Managed Outdoor Wi-Fi 6 Access Point The Cisco Meraki MR78 is a Dual-band, 802.11ax, 2x2:2, cloud managed entry level outdoor Access Point. Designed for basic, medium-density deployments, the MR78 provides enterprise grade security and simple management in a ruggedized IP67-rated form factor. The MR78 provides a maximum of 1.5 Gbps* aggregate frame rate with concurrent 2.4 GHz and 5 GHz radios. With the combination of cloud management, high performance hardware, multiple radios, and advanced software features, enterprise-grade security, the MR78 makes an outstanding platform to provide reliable Wi-Fi for small business and home office networks that want reliable and secure wireless connectivity MR78 and Meraki Cloud Management Management of the MR78 is performed through the Meraki cloud, with an intuitive browser-based interface that enables rapid deployment without time- consuming training or costly certifications. Because the MR78 is self-configuring and managed over the web, it can be deployed at a remote location in a matter of minutes, even without on-site IT staff. 24x7 monitoring via the Meraki cloud delivers real-time alerts if a network encounters problems. Remote diagnostic tools enable immediate troubleshooting over the web so that distributed networks can be managed with a minimum of hassle. The MR78’s firmware is automatically kept up to date via the cloud. New features, security fixes, and enhancements are delivered seamlessly over the web. This 1 means no manual software updates to download or missing security patches to worry about.

Specifications

Data transmission
Maximum data transfer rate	54 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
VLAN support	Yes
Maximum data transfer rate	54 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Management features
VLAN support	Yes
Features
2.4 GHz	Yes
5 GHz	Yes
VLAN support	Yes
Maximum data transfer rate	54 Mbit/s
Bluetooth	Yes
Bluetooth version	5.0
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	54 Mbit/s
Maximum data transfer rate (5 GHz)	54 Mbit/s
Bluetooth Low Energy (BLE)	Yes
Security
Security algorithms	AES, EAP-SIM, EAP-TLS, EAP-TTLS, IPSec, WEP, WPA, WPA3
MAC address filtering	Yes
Wireless Intrusion Detection System (WIDS)	Yes
Ports & interfaces
DC-in jack	Yes
Power
Power over Ethernet (PoE)	No
DC voltage range	12 V
Design
Placement	Ceiling, In-wall, Wall
Product colour	White
Antenna
Antenna type	Internal
Weight & dimensions
Width	245 mm
Depth	115 mm
Weight	450 g
Height	30 mm
