HPE Networking Instant On Outdoor Access Point Dual Radio 2x2 Wi-Fi 6 (RW) AP27

Networking Instant On Outdoor Access Point Dual Radio 2x2 Wi-Fi 6 (RW) AP27

Reasons To Buy

Built to Withstand the Elements

The HPE Networking Instant On Access Point AP27 is water- and dust-resilient built to IP67 standards that make it suitable for outdoor use
The hardened outer shell is capable of withstanding the bitter cold and harsh temperatures of all seasons.
An operating temperature as low as -40°C and as high as 60°C makes the AP27 ideal for any environment.

Create a Custom Guest Access Experience

HPE Networking Instant On Access Point AP27 creates a new avenue of revenue by providing connectivity to customers and employees in outside spaces
Guests and Employees experience quick and easy onboarding with the free-to-setup captive portal from the Instant On app, or a web portal.
Keep customers engaged and staying longer with easy and intuitive guest access and be sure employees are more productive with any time wireless access.

802.11ax Wi-Fi Certified 6

The HPE Networking Instant On Access Point AP27 features Orthogonal Frequency-Division Multiple Access (OFDMA) which allows access points to handle multiple Wi-Fi 6 capable clients on each channel simultaneously, improving efficiency by boosting overall capacity and reducing latency.
Target Wake Time (TWT): Ideal for IoT devices that communicate infrequently, TWT establishes a schedule for when clients need to communicate with an AP, thereby reducing power consumption and extending client battery life.
Multiple Input, Multiple Output (MIMO) allows the access point to serve multiple clients (Wi-Fi 5 and Wi-Fi 6) simultaneously.

Description

The HPE Networking Instant On Access Point AP27 is a dual radio outdoor access point designed to keep your employees and customers productive outdoors. This Wi-Fi CERTIFIED 6™ access point supports up to 75 simultaneous users and offers modern Wi-Fi standards in a robust, tough casing. These dual-band omni-directional radios offer impressive range and the same great features as other enterprise-class access points, but without any ongoing subscription fees. The AP27 features integrated wall- or pole-mounting brackets in a ruggedized casing for flexible mounting configurations in outdoor environments. The AP27 offers Power over Ethernet (PoE) 802.3af (Class 4) with a fully-integrated management experience in the Instant On mobile app or web portal.

What is new supporting point:
Introducing new TEC Certified SKU (S3U62A) for India
Wi-Fi CERTIFIED 6™ support for up to 75 user devices.
Provide Wi-Fi for the outdoors.
IP67 rated for outdoor use from -40°C to 60°C.
The hardened external shell protects from rain, wind, and dust.
Great at extending Wi-Fi to a patio, outdoor workspace, or curbside deliveries.

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	1774 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Spread spectrum method	OFDMA
Number of users	75 user(s)
Networking standards	IEEE 802.11ax
Ethernet LAN data rates	10,100,1000 Mbit/s
Certification	Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Maximum data transfer rate	1774 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Network
Spread spectrum method	OFDMA
Number of users	75 user(s)
Networking standards	IEEE 802.11ax
Ports & interfaces
I/O ports	1 GbE Base-T uplink port LED status indicators Reset button Kensington security slot
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security
Cable lock slot	Yes
Security algorithms	OWE, WPA2, WPA3
Features
2.4 GHz	Yes
5 GHz	Yes
Spread spectrum method	OFDMA
Number of users	75 user(s)
Networking standards	IEEE 802.11ax
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	1774 Mbit/s
MIMO type	Multi User MIMO
MIMO	Yes
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	1200 Mbit/s
Trusted Platform Module (TPM)	Yes
Power
Power consumption (typical)	14.6 W
Power over Ethernet (PoE)	Yes
Design
Placement	Ceiling, Pole, Wall
Product colour	White
Certification	Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Cable lock slot	Yes
Cable lock slot type	Kensington
Antenna
Antenna type	Internal
Antennas quantity	2
Antenna direction type	Omni-directional
Technical details
Mounting	Wall-mount bracket
Certificates
Certification	Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Weight & dimensions
Width	180 mm
Depth	232 mm
Weight	1.17 kg
Height	120 mm
Other features
Mounting	Wall-mount bracket
I/O ports	1 GbE Base-T uplink port LED status indicators Reset button Kensington security slot
Operational conditions
Operating temperature (T-T)	-40 - 65 °C
