TP-LINK

TP-Link Omada DR3220v-4G wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

SKU DR3220V-4G
£304.20
£238.62
£304.20
£238.62
Excluding taxes
2.4 GHz: 574 Mbps, 5 GHz: 2402 Mbps (HE160), 256 MB NAND, 512 MB DDR4, 393.5Mbps, 129.3Mbps, 126.7Mbps, 802.1Q VLAN, 50 Tunnels, CE, RoHS

Key Features

  • AX3000 WiFi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz*1*4
  • VDSL2 35b: Supports 350Mbps DSL Access*2
  • VDSL2/ADSL2+/ADSL2/ADSL Compatibility
  • Centralized Cloud Management
  • IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN
  • Load Balancing Between DSL and Ethernet WAN
  • Omada Mesh Technology*3
  • 3 × RJ11 Ports (2 × FXS, 1 × DSL) & 5 × RJ45 Gigabit Ports & 2 × USB 3.0 Ports
  • Desktop/Wall Mounting
  • 8.9 × 5.2 × 1.4 in (226 × 131.2 × 35 mm)

Description

Specifications

Ethernet LAN features
Ethernet WAN Yes
Ethernet LAN interface type Gigabit Ethernet
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
DSL features
DSL WAN Yes
ADSL Yes
ADSL2 Yes
ADSL2+ Yes
VDSL2 Yes
Mobile network
SIM card slot No
3G/4G USB modem compatibility Yes
Network
Network address translation (NAT) Yes
Guest access Yes
Ethernet LAN interface type Gigabit Ethernet
Ethernet LAN Yes
VPN support IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates 10,100,1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
Port triggering Yes
Built-in FTP server Yes
Static route Yes
Policy-based routing Yes
Load balancing system Yes
Dynamic DNS (DDNS) Yes
Protocols
DMZ support Yes
Voice codecs G.711a, G.711ulaw, G.722, G.726, G.729ab
Universal Plug and Play (UPnP) Yes
DHCP server Yes
DHCP client Yes
Management features
Universal Plug and Play (UPnP) Yes
Web-based management Yes
Reset button Yes
Quality of Service (QoS) support Yes
MU-MIMO technology Yes
Security
VPN support IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE, SSL VPN
URL filtering Yes
System event log Yes
Security algorithms WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Network address translation (NAT) Yes
Guest access Yes
DMZ support Yes
Access Control List (ACL) Yes
Performance
Voice codecs G.711a, G.711ulaw, G.722, G.726, G.729ab
Packaging content
Package type Box
Number of products included 1 pc(s)
Cables included LAN (RJ-45), Phone
AC adapter included Yes
Antenna included Yes
WAN connection
Ethernet WAN Yes
DSL WAN Yes
SIM card slot No
3G/4G USB modem compatibility Yes
WAN connection type RJ-45
Wireless LAN features
WLAN data transfer rate (max) 2402 Mbit/s
Wi-Fi band Dual-band (2.4 GHz / 5 GHz)
WLAN data transfer rate (first band) 574 Mbit/s
WLAN data transfer rate (second band) 2402 Mbit/s
Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ports & interfaces
USB port Yes
RJ-11 ports quantity 3
Ethernet LAN (RJ-45) ports 4
DC-in jack Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Design
Product type Tabletop router
Wall mountable Yes
LED indicators DSL, LAN, USB, WLAN
Product colour Black
Indication light Yes
Antenna
Antenna design External
Detachable antenna(s) Yes
Antennas quantity 3
Antenna gain level (max) 4.5 dBi
Power
Power source type AC
Output voltage 12 V
Output current 3.3 A
Operational conditions
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 5 - 90%
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Width 226 mm
Height 35 mm
Depth 131 mm
Packaging data
Package type Box
Cables included LAN (RJ-45), Phone
AC adapter included Yes
Number of products included 1 pc(s)
Antenna included Yes
