TP-Link XX530V wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black

AX3000 Dual Band WiFi 6 GPON Router

Key Features

• Dual-Band WiFi 6: Enjoy smooth streaming, gaming, and fast downloading all at the same time with WiFi speeds up to 3 Gbps across two bands.*
• Boosted Coverage: High-performance antennas and beamforming technology combine to extend strong, reliable WiFi throughout your home.
• More Connections: OFDMA and MU-MIMO technologies increase capacity and enable simultaneous transmission to more devices.**
• EasyMesh Compatible: Create a smart mesh network with seamless coverage and greater flexibility based on standard mesh technology.†
• Versatile Internet Access: Supports direct GPON fiber access, Ethernet connections via modem, and 3G/4G internet services through the USB port.
• Gigabit Wired Connections: 1× GbE WAN/LAN port and 3× GbE LAN ports provide fast and flexible internet access.
• VoIP Calls: Supports multiple VoIP accounts and various call features to surpass traditional landlines.
• Enhanced Security: WPA3 encryption, Multi-SSID, and parental controls provide personalized and safer online experiences.**
• Compact Fiber Tray Design: Store a redundant fiber cable inside and protect the fiber cable from breaking.
• Easy Setup and Use: Simplifies network and WiFi control and management via the powerful Aginet app.
• Remote Management: Supports TAUC (TP-Link Aginet Unified Cloud, based on TR-369) along with OMCI, TR-069, TR-098, TR-181, TR-111, and TR-143 protocols.

Description

Next Wave of WiFi 6 for Upgraded Home Connectivity
AX3000 Dual-Band WiFi 6 GPON Router

Dual-Band WiFi 6 Up to 3.0 Gbps
Wi-Fi 6 (802.11ax) technology brings faster speeds, less lag, and higher capacity, enabling more simultaneous connections on your home network. Every application feels more fluid with drastically improved WiFi speeds. Both the 2.4 GHz band and 5 GHz band get upgraded to the latest generation—perfect for 4K/8K streaming, online gaming, and fast downloading.

More Connections at High Speed
Easily handle dozens of devices streaming and gaming at the same time. OFDMA and MU-MIMO future-proof your home network by providing greater capacity to connect more devices.

OFDMA
OFDMA separates a single spectrum into multiple units and enables different devices to share one transmission stream, increasing efficiency and reducing latency.

MU-MIMO
Simultaneously transfers data to multiple devices for 2× faster performance.

Extensive WiFi Coverage
High-performance dual-band antennas and beamforming technology combine to adapt WiFi coverage to perfectly fit your home and concentrate signal strength towards every device.

Smart Mesh WiFi with Greater Flexibility
Create a unified mesh WiFi network with other EasyMesh-compatible router or mesh AP for seamless whole home coverage.

Whole Home Coverage
Eliminate weak signal areas with WiFi coverage for your entire home

Seamless Roaming
Uninterrupted streaming when moving around your home

One WiFi Name
No more switching WiFi network names when you walk around

Versatile Connectivity
With multiple connection ports, XX530v provides you with a variety of internet connection options. The PON port delivers up to 2.5 Gbps internet access, catering to your high-speed home. The Ethernet WAN/LAN port supports wired connections to modems or switches via Ethernet cabling. A 3G/4G dongle can be attached to the USB port as a backup to always stay connected.

Convenient VoIP Calls over the Internet
XX530v integrates a high-performance phone system. You can connect your analog phone to the router with voicemail storage and various VoIP call features, such as caller ID, call waiting, call holding and call forwarding to surpass traditional landlines.

Gigabit Wired Connections and Fast Media Sharing
The Gigabit Ethernet ports allow you to take full advantage of your broadband speed up to 1 Gbps. Plug your PCs, smart TVs, and game consoles into one of the Gigabit Ethernet LAN ports (including the WAN/LAN port) for reliable wired connections. The USB port can be used to share files, music, and videos within your network at high speeds.

WPA3 Security
Higher password safety and enhanced protection against brute-force attacks†

Parental Controls
Block inappropriate content and restrict time spent online

Multi-SSID
Create separate networks for visitors and keep your main network secure

Easy to Set Up and Use
You can set up your device and network in minutes, whether you prefer the powerful Aginet app or the intuitive web interface. The Aginet app allows you to manage your network from a smartphone or tablet.

Centralized Remote Management
Service provider can remotely configure and manage devices via their ACS (Auto-Configuration Server, based on TR-369/069) system or the OMCI (ONU Management Control Interface) protocol. High-level operations are also supported thanks to compatibility with TR-181, TR-111, and TR-143 protocols. While the home user can enjoy more efficient service experiences.

Aginet Solution: End-to-End Management Platform for ISPs
The Aginet solution offers ISPs powerful and flexible platforms to manage multiple devices for connected homes, such as dynamic service provisioning, zero-touch firmware upgrading, and remote troubleshooting and mesh WiFi diagnostics.

Specifications

Ethernet LAN features
Ethernet WAN	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN data rates	1000,100 Mbit/s
DSL features
DSL WAN	No
Mobile network
SIM card slot	No
3G/4G USB modem compatibility	No
Network
Network address translation (NAT)	Yes
Guest access	Yes
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN	Yes
Port forwarding	Yes
Ethernet LAN data rates	1000,100 Mbit/s
Port triggering	Yes
VPN server	PPTP VPN, IPSec VPN , OpenVPN
SSID-based VLAN assignment	Yes
Dynamic DNS (DDNS)	Yes
PPPoE/PPTP/L2TP pass-through	Yes
Protocols
DMZ support	Yes
Universal Plug and Play (UPnP)	Yes
DHCP server	Yes
DHCP client	Yes
Management features
Universal Plug and Play (UPnP)	Yes
WPS push button	Yes
Reset button	Yes
Quality of Service (QoS) support	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Intelligent Mesh technology	Yes
Traffic statistics	Yes
WAN connection
Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	No
Wireless LAN features
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2402 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11ad, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Ports & interfaces
USB port	Yes
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
SC/APC GPON ports quantity	1
Security
URL filtering	Yes
Security algorithms	WPA, WPA2, WPA3
Network address translation (NAT)	Yes
MAC address filtering	Yes
IP address filtering	Yes
Guest access	Yes
Firewall	Yes
DMZ support	Yes
Filtering	Yes
Schedule access	Yes
Parental control	Yes
IGMP snooping	Yes
Design
Product type	Tabletop router
Product colour	Black
Antenna
Antenna design	External
Antennas quantity	2
Transmit power	<20 dBm (2.4 GHz); <23 dBm (5 GHz)
Power
Power source type	AC
Output voltage	12 V
Output current	1.5 A
Operational conditions
Storage temperature (T-T)	-40 - 60 °C
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90%
