Ubiquiti LTE Backup Pro gateway/controller 10, 100, 1000 Mbit/s

74 Kc MIPS processor at 775 MHz, 128 MB DDR2, 2x GbE RJ45 ports, 2 x 2 LTE Category 4, nano-SIM, 44-57V DC, 1.54" screen, Polycarbonate, white

Description

ONLY COMPATIBLE WITH UNIFI OS CONSOLES SUCH AS UDM/UDM-PRO

Third-Party SIM Card Support

Avoid internet downtime and lost productivity by adding a UniFi LTE Pro to your existing UniFi network.

UniFi LTE Pro provides backup cellular internet connectivity to ensure your UniFi WAN network is always running. This model works in the EU region and supports European LTE and WCDMA bands. It has a Nano SIM card slot for your own card. Insert the Nano SIM, connect to any switch port in your corporate network, and activate the device.

Features:

Automatic redundant WAN connection
Integrated with UniFi Network application
PoE (802.3af) powered
Nano SIM card slot
Supports European bands: LTE (1, 3, 7, 8, 20, 28), WCDMA (1, 8)
Coverage and speed depend on the mobile network.
Requires UniFi Security Gateway or UniFi Dream Machine.

Managed with UniFi Network Application Version: 5.14.0or higher.

Note:This device only supports UniFi Network setups hosted by a UniFi OS Console.

Specifications

Design
Mounting type	Desktop/Wall mounting
Product colour	Grey, White
Enclosure material	Polycarbonate (PC)
Features
Antenna type	Internal
Antenna connector type	RP-SMA
Antennas quantity	2
Built-in processor	Yes
Processor frequency	775 MHz
Performance
Built-in processor	Yes
Processor frequency	775 MHz
Internal memory type	DDR2
Internal memory	128 MB
Display type	LCM
Control display unit	Yes
Processor model	MIPS32 74Kc
Processor manufacturer	MIPS
Mounting type	Desktop/Wall mounting
Product colour	Grey, White
Enclosure material	Polycarbonate (PC)
Network
Ethernet LAN data rates	10,100,1000 Mbit/s
4G LTE category	4
Data network	4G
Downlink/uplink speed	150 / 50 Mbit/s
Ports & interfaces
WAN connection	Ethernet (RJ-45)
Number of simultaneous SIM cards	1
Ethernet LAN (RJ-45) ports	2
SIM card type	NanoSIM
SIM card slot	Yes
Management features
Web-based management	Yes
Reset button	Yes
Power
Power supply	0.5 W
Power over Ethernet (PoE)	Yes
DC input voltage	44 - 57 V
Power consumption (max)	8.5 W
Weight & dimensions
Weight	223 g
Width	66 mm
Height	202 mm
Depth	32 mm
Operational conditions
Operating temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	5 - 95%
Sustainability
Sustainability compliance	Yes
Technical details
Built-in processor	Yes
Antenna type	Internal
Processor frequency	775 MHz
Number of simultaneous SIM cards	1
Antenna connector type	RP-SMA
Sustainability compliance	Yes
Compliance certificates	CE, Federal Communications Commission (FCC)
Memory
Internal memory type	DDR2
Internal memory	128 MB
Display
Display type	LCM
Control display unit	Yes
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC)
Antenna
Antenna type	Internal
Antenna connector type	RP-SMA
Antennas quantity	2
