Ubiquiti NanoStation 5AC Loco 1000 Mbit/s White Power over Ethernet (PoE)

NanoStation AC Loco, 10/100/1000 Mbps Ethernet Port, Atheros MIPS 74Kc, 560 MHz, 64 MB DDR2, 179 x 77.5 x 59.1 mm

Description

The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.

Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.

Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.

Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.

Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

Specifications

Data transmission
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Performance
5 GHz	Yes
Frequency band	5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
Maximum outdoor range	10000 m
Ethernet LAN data rates	10,100,1000 Mbit/s
Certification	CE, FCC, IC
Maximum data transfer rate	1000 Mbit/s
Operating system installed	AirOS
Internal memory	64 MB
Built-in processor	Yes
Wireless LAN features
Frequency band	5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
Maximum outdoor range	10000 m
Memory
Internal memory	64 MB
Features
5 GHz	Yes
Frequency band	5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
Maximum outdoor range	10000 m
Ethernet LAN data rates	10,100,1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Throughput data rate	450 Mbit/s
Operating system installed	AirOS
Internal memory	64 MB
Built-in processor	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Yes
Input current	0.5 A
AC input voltage	24 V
Design
Placement	Ceiling
Product colour	White
LED indicators	Network, Power, Signal strength
Certification	CE, FCC, IC
Antenna
Antenna type	Internal
Technical details
Harmonized System (HS) code	85176990
Processor
Built-in processor	Yes
Certificates
Certification	CE, FCC, IC
Indication
LED indicators	Network, Power, Signal strength
Weight & dimensions
Width	179 mm
Depth	77.5 mm
Weight	180 g
Height	59.1 mm
Operational conditions
Operating relative humidity (H-H)	5 - 95%
Operating temperature (T-T)	-40 - 70 °C
Logistics data
Harmonized System (HS) code	85176990
